Installation Chart
Mobile Series MS08
7
03
필요할 경우 3.5”베이를
빼냅니다.
如果需要請移除3.5吋
檔板。
如果需要请移除3.5吋
檔板。
必要であれば3.5″ベイ
を外します。
Remove 3.5″bay over if
needed.
При необходимости,
извлеките отсек для
3,5-дюймового диска.
Entfernen Sie die
Abdeckung des
3,5-Zoll-Schachts, falls
erforderlich.
Retirez le couvercle de
la baie 3,5" si
nécessaire.
Retire la cobertura de
la bahía de 3,5” si es
necesario
Rimuovere l’alloggio da
3,5”, se necessario.
04
3.5” 드라이브 베이에
랙을 끼웁니다.
安裝至3.5吋槽位。
安装至3.5吋槽位。
ラックを3.5″ドライ
ブベイに入れます。
Insert rack into 3.5″
drive bay.
Установите
устройство в отсек
для 3,5-дюймового
диска.
Setzen Sie das Rack in
den 3,5-Zoll-
Laufwerkschacht ein.
Insérez le rack dans la
baie de lecteur 3,5".
Inserte el rack en la
bahía para dispositivo
de 3,5”
Inserire il rack nell’
alloggio da 3,5”.
