Installation Chart
Mobile Series MS08
9
07
전원 공급장치의 SATA
전원 케이블을 연결합니다.
將電源供應器的SATA 電源
線連接至裝置。
将电源供应器的SATA 电源
线连接至装置。
電源からのSATA電源
ケーブルを接続します。
Connect SATA power
cable from the power
supply.
Подключите кабель
питания SATA от
блока питания.
Verbinden Sie das
SATA-Stromkabel mit
dem Netzteil.
Branchez le cordon
d'alimentation sur la
source d'alimentation
Conecte el cable de
potencia SATA a la
fuente de alimentación
Collegare il cavo
d'alimentazione SATA
dall'alimentatore.
08
PC 케이스를 닫아서
설치를 완료합니다.
關上機殼完成安裝。
关上机壳完成安装。
PCケースを閉めると、
インストール完了です。
Close PC case to
complete installation.
Для завершения
установки закройте
корпус ПК.
Schließen Sie das
PC-Gehäuse; damit ist
die Installation
abgeschlossen.
Refermez le boîtier du
PC pour terminer
l'installation.
Cierre la carcasa del
PC para completar la
instalación
Chiudere il case PC per
completare l'installazione.
SATA 15 PIN
SATA 7 PIN
Confirm
1
2
Raid 0
Raid 1
JBOD
