Installation Chart
Mobile Series MS08
11
03
도어를 닫습니다.
關上門檔。
关上门档。
ドアを閉めます。
Close the door. Закройте дверцу.
Schließen Sie die Tür.
Refermez le volet.
Cierre la puerta.
Chiudere lo sportello.
04
설치되어 있는 드라이브
를 꺼내려면그림과 같이
도어를 열고 눌러서 뺍
니다.
如圖示打開門檔到底，
往內按壓以彈出硬碟。
如图示打开门文件到底，
往内按压以弹出硬盘。
装着されたドライブを取
り出すには、ドアを開け
て図のように元に戻し
ます。
To eject installed
drives, open the door
and push it back as
shown.
Для извлечения
установленных дисков
откройте дверцу и
нажмите на нее в
направлении стрелки
(см. рис.).
Zum Auswerfen der
installierten Laufwerke
öffnen Sie die Tür und
drücken sie wie
abgebildet nach hinten.
Pour éjecter les disques
installés, ouvrez la
trappe et éjectez-les
comme indiqué.
Para eyectar los discos
instalados, abra la
puerta y empuje hacia
atrás como se muestra.
Per espellere le unità
installate, aprire lo
sportello e spingerlo,
come mostrato.
