Top and front panels (see page 2)
1. VOLUME
 adjust volume level.
2. FUNCTION SWITCH
 select source of sound MP3/CD,TAPE
or RADIO, also the power off switch.
3. HEADPHONE JACK
 3.5 mm stereo headphone jack.
4. CD DOOR
 Lift the CD lid to open/close the
CD door.
5. CASSETTE RECORDER KEYS
PAUSE (
;;
)
 interrupts recording or playback.
STOP /EJECT( ) stop the tape
 opens the cassette compartment
F.FWD (
77
) fast winds
F.REW (
88
) rewinds the tape
PLAY (
44
) starts playback.
RECORD ( )- starts recording
6. CASSETTE DOOR
Press stop/eject to open/close the
cassette door
7. BAND SELECTOR(FM ST FM AM)
selects (FM ST. /FM/AM) waveband.
8. TUNING CONTROL
 selects FM/AM stations.
9. RANDOM
CD:  play CD/MP3 tracks in random order
10. SEARCH BACK( 9 )
CD:  Skip orsearch a passage/track
backwards
11. REPEAT BUTTON
repeat track MP3/CD/program
12. PLAY/PAUSE BUTTON (
44;;
)
 start or pauseCD/MP3 play
13. SEARCH NEXT (
:
)
CD: Skip or search a passage/track
forwards.
14. STOP BUTTON ()
 stop MP3/CD playback
15.REMOTE SENSOR
16. DIAL POINT WINDOW
 show the number of tracks
17. BATTERIES COMPARTMENT
 put batteries into it.
18. VOLTAGE SELECTOR
 adjust to match the local voltage
before plugging in the set
19. AC MAINS
 inlet for power cord.
20. FM ANTENNA
 to improve FM reception
Remote Control Handset (see page 2)
21. PROGRAM  program and review programmed track
numbers.
22.-28.
The remote control buttons function is the same as
the button of CD/MP3 section . Select the CD
tracks by (+10)/(-10)button.
Power Supply
Using AC Power
1. Check if the power voltage, as shown on the type plate
located on the bottom of the set, corresponds to your
local AC power supply. If it does not, consult your dealer
or service centre.
2. Connect the power cord to the AC MAINS inlet and the
wall outlet. The power supply is now connected and
ready for use.
3. To switch off completely, unplug the power cord from the
wall outlet.
=
Unplug the power cord from the wall outlet to protect
your set during heavy thunderstorms.
Batteries (not included)
Open the battery compartment and insert eight batteries,
type R-14, UM-2 or C-cells, (preferably Alkaline) with the
correct polarity as indicated by the "+" and "-" symbols
inside the compartment.
Batteries contains chemical substances, so they
should be disposed of properly.
Incorrect use of batteries can cause electrolyte leakage and
will corrode the compartment or cause the batteries to burst.
Therefore:
=
Do not mix battery types: e.g. alkaline with carbon Zinc.
Only use batteries of the same type for the set.
=
When inserting new batteries, do not try to mix old bat-
teries with new ones.
=
Remove the batteries if the set is not be used for a long
time.
ENGLISH
4
3469.qxd 13.05.05 11:58 Page 4
