Philips FC9264 [9/184] Telescopic tube

Note: This vacuum cleaner has been tted with holes (specic types only) at the end of the handgrip.

These holes may prevent objects from getting stuck or damaged when you use your vacuum cleaner

without the tube or accessories supplied.

Hose

1 Toconnectthehose,pushitrmlyintotheappliance(‘click’)(Fig.11).

2 To disconnect the hose, press the release button (1) and pull the hose out of the appliance

(2) (Fig. 12).



1 Adjust the length of the tube in such a way that the hand holding the standard handgrip is at

hip level (Fig. 13).

2 Hold the tube so that the standard handgrip is at hip level. (Fig. 8)

3 To connect the tube to a nozzle, press the spring-loaded lock button on the tube and insert

the tube into the nozzle. Fit the spring-loaded lock button into the opening in the nozzle

(‘click’) (Fig. 14).



1 Slide the accessory holder onto the handgrip (‘click’) (Fig. 15).

2 Push the accessories onto the holder. (Fig. 16)

3 To detach the accessory holder, squeeze the release levers together (1) and slide the

accessory holder off the handgrip (2) (Fig. 17).



1 Connect the crevice tool (1) or small nozzle (2) with or without brush attachment directly

to the standard handgrip or to the tube (Fig. 18).

Brush attachment

1 To assemble the brush attachment, slide it onto the bottom of the small nozzle

(‘click’) (Fig. 19).

2 To disassemble the brush attachment, slide it off the bottom of the small nozzle (Fig. 20).



The Tri-Active nozzle is a multi-purpose nozzle for carpets and hard oors.

- The side brushes catch more dust and dirt at the sides of the nozzle and allow you to clean

better along furniture and other obstacles (Fig. 21).

- The opening at the front of the nozzle allows you to suck up larger particles (Fig. 22).

1 Usethehardoorsettingtocleanhardoors(forinstancefortiled,parqueted,laminated

andlinoleumedooring):pushtherockerswitchontopofthenozzlewithyourfootto

make the brush strip come out of the housing. At the same time, the wheel is lifted to

prevent scratching and to increase manoeuvrability (Fig. 23).

2 Usethecarpetsettingtocleancarpets:pushtherockerswitchagaintomakethebrushstrip

disappear into the nozzle housing. The wheel is lowered automatically (Fig. 24).



You can use the combination nozzle on carpets (with the brush strips folded in) or on hard oors

(with the brush strips folded out).

ENGLISH 9
