Hertz DCX 690.3 [10/11] Owner s manual
![Hertz DCX 690.3 [10/11] Owner s manual](/views2/1075681/page10/bga.png)
Component
Size
mm (in.)
Impedance
Ω
Power
handling
W peak
W continuous
/ х Технически спецификации / 㔏㦾屓㔏㦾屓㫋 / ehnički podaciTehnički podaci
/ Technické údaje / Technical specifications / Tehnilised andmed /
Tekniset tiedot / Caractéristiques techniques / Technische daten
/ εχνικά χαρακτηριστικάΤεχνικά χαρακτηριστικά / Műszaki adatok / Spesifikasi teknis /
Specifiche tecniche / 技術仕様技術仕様// ꩡ韥ꯕ ꩡ꽆 / Techniniai duomenys /
Szczegóły zSzczegóły techniczne / Especificações técnicas / Технические
условия / Technické informácie / Tehnične specifikacije / Especificaciones
técnicas / Tekniska specifikationer / ࠻࡞ࡩࡘࡌࡼࡤ࠾࠸ࡩ࡚ࡎࡩ࠾ࡳࡎ࠻ࡐ࠻ / eknik Teknik
verilerveriler
Sensitivity
dB/SPL
Frequency
response
Hz
Magnet
Dome / Cone
kg (lb.)
Weight of one
component
DCX 87.3
Two way Woofer 87 (3.4)
60 30 4 130 ÷ 21k 92
60 x 24 x 8 (2.4 x 0.9 x 0.3) 20 (0.8)
High density ux ferrite Water-repellent pressed paper
0,31 (0.68)
coaxial Tweeter 15 (0.6) Neodymium PEI
DCX 100.
3
Two way Woofer 100 (4.0)
60 30 4 70 ÷ 21k 92
70 x 32 x 10 (2.7 x 1.3 x 0.4) 25 (1.0)
High density ux ferrite Water-repellent pressed paper
0,45 (0.99)
coaxial Tweeter 15 (0.6) Neodymium PEI
DCX 130.
3
Two way Woofer 130 (5.0)
80 40 4 65 ÷ 21k 93
70 x 32 x 15 (2.7 x 1.3 x 0.6) 25 (1.0)
High density ux ferrite Water-repellent pressed paper
0,56 (1.23)
coaxial Tweeter 15 (0.6) Neodymium PEI
DCX 165.
3
Two way Woofer 165 (6.5)
120 60 4 60 ÷ 21k 93
80 x 40 x 15 (3.1 x 1.6 x 0.6) 25 (1.0)
High density ux ferrite Water-repellent pressed paper
0,77 (1.69)
coaxial Tweeter 15 (0.6) Neodymium PEI
DCX 170.
3
Two way Woofer 170 (6.7)
100 50 4 60 ÷ 21k 93
80 x 32 x 10 (3.1 x 1.3 x 0.4) 25 (1.0)
High density ux ferrite Water-repellent pressed paper
0,56 (1.23)
coaxial Tweeter 15 (0.6) Neodymium PEI
DCX 460.
3
Two way Woofer - (4.0
x
6.0)
80 40 4 65 ÷ 21k 93
80 x 32 x 10 (3.1 x 1.3 x 0.4) 25 (1.0)
High density ux ferrite Water-repellent pressed paper
0,58 (1.28)
coaxial Tweeter 15 (0.6) Neodymium PEI
DCX 570.
3
Two way Woofer - (5.0
x
7.0)
120 60 4 60 ÷ 21k 93
80 x 40 x 15 (3.1 x 1.6 x 0.6) 25 (1.0)
High density ux ferrite Water-repellent pressed paper
0,76 (1.67)
coaxial Tweeter 15 (0.6) Neodymium PEI
DSK 130.
3
Two way Woofer 130 (5.0)
120 60 4 60 ÷ 23k 93
70 x 32 x 15 (2.7 x 1.3 x 0.6)
25 (1.0)
High density ux ferrite Water-repellent pressed paper
0,53 (1.17)
system Tweeter 24 (0.9) - - Neodymium PEI 0,03 (0.07)
DSK 165.
3
Two way Woofer 165 (6.5)
160 80 4 50 ÷ 23k 93
80 x 40 x 15 (3.1 x 1.6 x 0.6)
25 (1.0) High density ux ferrite Water-repellent pressed paper
0,74 (1.63)
system Tweeter 24 (0.9) - - Neodymium PEI 0,03 (0.07)
DSK 170.
3
Two way Woofer 170 (6.7)
160 80 4 50 ÷ 23k 93
80 x 32 x 10 (3.1 x 1.3 x 0.4)
25 (1.0)
High density ux ferrite Water-repellent pressed paper
0,53 (1.17)
system Tweeter 24 (0.9) - - Neodymium PEI 0,03 (0.07)
DCX 690.3
Three way
Woofer - (6.0
x
9.0)
180 90 4 45 ÷ 21k 93
80 x 40 x 15 (3.1 x 1.6 x 0.6) 25 (1.0)
High density ux ferrite Water-repellent pressed paper
0,95 (2.09)
coaxial
Tweeter 60 (2.5) High density ux ferrite Water-repellent pressed paper
Super Tweeter 15 (0.6) - PEI
DCX 710.
3
Three way
Woofer - (7.0
x
10.0)
300 150 4 40 ÷ 21k 93
90 x 32 x 17 (3.5 x 1.3 x 0.7) 25 (1.0)
High density ux ferrite Water-repellent pressed paper
1,35 (2.97)
coaxial
Tweeter 60 (2.5) High density ux ferrite Water-repellent pressed paper
Super Tweeter 15 (0.6) - PEI
DT 24.
3 Tweeter
24 (0,9)
80 W @ 3,5 kHz
- 4 3k ÷ 23k 94 - - Neodymium PEI 0,03 (0.07)
6 dB Oct.
mm (in.)
Voice coil Ø
mm (in.)
Magnet size
Specific
component
Size
mm (in.)
kg (lb.)
Crossover
weight
Type - Cut off
DX 100.3
DT 24.3
26 x 44 x 20 0,10
Hi-Pass
Crossover (1.0 x 1.7 x 0.8) (0.22) 3,5 kHz @ 6 dB Oct.
DX 300.3
DV 130.3 / DV 165.3 / DV 170.3 / DT 24.3
45 x 75 x 21 0,16
Hi-Pass
Crossover (1.8 x 3.0 x 0.8) (0.35) 3,5 kHz @ 12 dB Oct.
Owner’s Manual
2726
