ENGLISH en
9
External extraction:
Remove the dust collection box (6) to the rear.
Connect a suitable extraction device to the ejection
nozzle. Use a suction hose with a 35 mm connector
diameter.
Empty dust collection box (6).
- Open cleaning flap (7).
- Empty dust collection box (6).
- Remove fluted filter (8) and knock off dust stuck to
filter or remove with brush.
- When inserting, ensure that the fluted filter (8) is
inserted in the lateral guides.
Clean the machine regularly. This includes
vacuum cleaning the ventilation louvres on the
motor.
Replacing a worn support plate
- Remove the locking screw (9) of the support plate.
- Remove support plate (2).
- For replacement support plates, refer to the
Accessories chapter.
- Mount support plate (2) and rotate until it engages
on carrier disc.
-Insert locking screw (9) again and tighten.
Replacing support plate brake / braking ring
If the idling speed of the support plate increases in
course of time, the braking ring (10) is worn and
must be replaced.
Note:
If abrasive material (e.g. gypsum, etc.) is
being sanded, the braking ring inevitably wears
faster.
- Remove the locking screw (9) of the support plate.
- Remove support plate (2).
- Replace the old braking ring (10) with the new
braking ring (Order No.: 344097450), ensuring
that the new braking ring is in the same position as
the old braking ring.
- Mount support plate (2) and rotate until it engages
on carrier disc.
-Insert locking screw (9) again and tighten.
Use only genuine Metabo accessories.
See page 4.
Use only accessories which fulfil the requirements
and specifications listed in these operating instruc-
tions.
A Support plate with velcro-type fastening,
medium-hard
BSupport plate with velcro-type fastening, soft
C Adhesive intermediate disc
D Adhesive sanding discs
E Adhesive polishing sponge
F Lambskin adhesive polishing disc
G Adhesive polishing felt
H Adhesive sanding fleece
I Adhesive sanding screen
J Fluted filter (as replacement)
K Dust collection box (as replacement)
L Metabo universal vacuum cleaner
MAdapter
NSuction hose
For complete range of accessories, see
www.metabo.com or the main catalogue.
Repairs to electrical tools must be carried out
by qualified electricians ONLY!
If you have Metabo electrical tools that require
repairs, please contact your Metabo service centre.
For addresses see www.metabo.com.
You can download spare parts lists from
www.metabo.com.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Only for EU countries: Never dispose of
power tools in your household waste! In
accordance with European Guideline 2002/
96/EC on used electronic and electric equipment
and its implementation in national legal systems,
used power tools must be collected separately and
handed in for environmentally compatible recycling.
Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
D =Diameter of support plate
P
1
=Nominal power input
P
2
=Power output
n
0
=Idle speed
n
1
=Speed at rated load
s
0
=Oscillating frequency at idle speed
s
1
=Oscillating frequency at rated load
S =Oscillating circuit diameter
C =Dust collection box
m =Weight without mains cable
Measured values determined in conformity with
EN 60745.
Machine in protection class II
~ Alternating current
The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).
Emission values
These values make it possible to assess the
emissions from the power tool and to compare
different power tools. Depending on the operating
conditions, the condition of the power tool or the
accessories, the actual load may be higher or lower.
For assessment purposes, please allow for breaks
and periods when the load is lower. Based on the
adjusted estimates, arrange protective measures
for the user e.g. organisational measures.
Vibration total value
(vector sum of three directions)
determined in accordance with EN 60745:
8. Cleaning, Maintenance
9. Accessories
10. Repairs
11. Environmental Protection
12. Technical Specifications
