3.5.3 User settings menu
User settings menu: Parameters (short)
The user settings menu ( ) comprises parameters that can be
changed and adjusted by users. You can read out and adjust the
parameters according to your preferences.
NOTICE
If you are not sure about the function of the parameter, do
not change it. Contact your service agent.
# Description Unit Default Range
U00 Summer-winter switch over
temperature
°C 20 10~30
U01 Heating slope — 0 0~40
U02 Central heating ECO mode — 0 0~1
U03 Domestic hot water comfort
mode
— 0 0~1
U04 Domestic hot water set value °C 50 35~60
U05 Set value for the room
thermostat at day mode
°C 21 10~30
U06 Set value for the room
thermostat at reduced mode
°C 18 10~30
U07 Set value for the flow
temperature at day mode
°C 50 30~80
U08 Set value for the flow
temperature at reduced mode
°C 35 30~80
U09 Domestic hot water comfort
mode user record dependency
— 1 1, 2 or
24
U10 Room temperature setpoint
used by Daikin room thermostat
during night
°C 18 10~30
t00
(a)
Year — 1~99
t01
(a)
Mounth — 1~12
t02
(a)
Day — 1~31
t03
(a)
Hour — 0~23
t04
(a)
Minute — 0~59
(a) Applicable if energy metering is enabled.
User settings menu: Parameters (detailed)
# Description
U00 When using outdoor sensor, above this parameter
value of outside temperature, the boiler senses the
season as summer and does not activate central
heating although there is demand. Summer-winter
switching has a hysteresis of ±1ºC.
i.e: When this parameter is adjusted to 20ºC, the boiler
switches to summer mode at 21ºC and switches back
to winter mode at 19ºC.
U01 This value is used when only outside sensor is
connected to the boiler (No Opentherm room
thermostat connection). The parameter heating slope is
important to adapt the weather compensation to the
individual heating system, the building and the thermal
insulation. The heating slope can be adjusted from 0
to 40. The heating slope needs to be increased to
increase the boiler central heating set temperature.
Colder regions require a higher heating slope value.
Note: To activate weather compensation, the heating
slope value must be higher than "5".
U02 Enabling / disabling central heating ECO mode.
1 = enabled, 0 = disabled
# Description
U03 Enabling / disabling domestic hot water comfort mode.
1 = enabled, 0 = disabled
U04 Domestic hot water set value (same function that can
be done via the right dial when domestic hot water
mode is enabled).
U05 When On-Off room thermostat and outdoor sensor are
both connected, this parameter value is the virtual room
temperature setpoint when there is a heat demand.
U06 When On-Off room thermostat and outdoor sensor are
both connected, this parameter value is the virtual room
temperature setpoint when there is no heat demand.
Note: For this parameter value to be active, reducing
mode has to be enabled by your service agent,
otherwise central heating mode will not be activated
when there is no heat demand.
U07 When On-Off room thermostat is connected and
outdoor sensor is not connected, this parameter value
is the central heating water temperature setpoint when
there is a heat demand.
U08 When On-Off Room thermostat is connected and
outdoor sensor is not connected, this parameter value
is the central heating water temperature setpoint when
there is not a heat demand.
Note: For this parameter value to be active, reducing
mode has to be enabled by your service agent,
otherwise central heating mode will not be activated
when there is no het demand.
U09 If parameter is 1, comfort mode preheating will depend
on the user record. It will preheat the water according to
the previous day user records.
If parameter is 2, comfort mode preheating will be
independent of the user record, and at the highest
comfort level (3-star comfort according to EN13302).
If parameter is 24, comfort mode preheating will be
independent of the user record.
Note: If you increase the comfort level, the energy
consumption increases.
U10 Room temperature setpoint used by Daikin Opentherm
room thermostat during night mode. Only visible in case
Daikin Opentherm room thermostat is connected.
t00
(a)
t01
(a)
t02
(a)
t03
(a)
t04
(a)
The date and time are set by means of t parameters to
update the LAN adapter. This is needed in case the
LAN adapter does not have internet connection.
Time and date settings is saved when menu is quitted
by pressing (back) button.
After date and time are set, UH-08 error disappears.
(a) Applicable if energy metering is enabled.
To use the user settings menu
1 Press the "Enter" button when the icon is displayed on the
menu level 1 screen.
Result: You can see the parameter values on menu level 2.
2 Select U or t parameters with the left dial.
3 Select the index with the right dial.
4 Press the "Enter" button when the parameter that you want to
change is displayed.
Result: You can see the menu level 3 screen. Up and down
arrows will appear.
5 Change the parameter with the right dial.
