Outdoor Unit - RK(X)S42G2V1B, ARXS42G2V1B SiBE04-808_B
249 Removal Procedure
7
Remove the 8 screws in
total to remove the
PCB.
8
Lift up the back side
slightly and unfasten
the hooks of the front.
When reassembling, make
sure that the hooks of the
electrical box are placed on
the PCB.
9
Lift up the PCB.
Step
Procedure Points
(R8163)
(R8164)
(R8166)
Hooks
(R8167)
