SiBE04-808_B Outdoor Unit - RK(X)S42G2V1B, ARXS42G2V1B
Removal Procedure 250
10
Remove the PCB.
11
Detach the terminals
from the terminal board.
Refer to page 26 for detail.
[S20] : electronic expansion
valve coil
[S40] : overload protector
[S70] : fan motor
[S80] : four way valve coil
[S90] : thermistors
Step
Procedure Points
(R8168)
(R8169)
[S70] [S40]
[S90]
[S20]
[S80]
