Version 2.00 | Optidrive ODE-3 User Guide | 5www.invertekdrives.com
Quick Start Up
1
1.2. Quick Start Process
Step Action Page
1 Identify the Enclosure Type, Model Type and ratings of
your drive from the model code on the label. In particular
- Check the voltage rating suits the incoming supply
- Check the output current capacity meets or exceeds the
full load current for the intended motor
2.1. Identifying the Drive by Model Number 7
2 Unpack and check the drive. Notify the supplier and
shipper immediately of any damage.
3 Ensure correct ambient and environmental conditions for
the drive are met by the proposed mounting location.
9.1. Environmental 37
4 Install the drive in a suitable cabinet (IP20 Units) ensuring
suitable cooling air is available. Mount the drive to the
wall or machine (IP66).
3.1. General
3.3. Mechanical Dimensions and Mounting – IP20
Open Units
3.4. Guidelines for Enclosure Mounting – IP20 Units
3.5. Mechanical Dimensions – IP66 (Nema 4X)
Enclosed Units
3.6. Guidelines for mounting (IP66 Units)
9
9
10
11
12
5 Select the correct power and motor cables according
to local wiring regulations or code, noting the maximum
permissible sizes
9.2. Rating Tables 37
6 If the supply type is IT or corner grounded, disconnect the
EMC filter before connecting the supply.
9.5. EMC Filter Disconnect 38
7 Check the supply cable and motor cable for faults or short
circuits.
8 Route the cables
9 Check that the intended motor is suitable for use, noting
any precautions recommended by the supplier or
manufacturer.
4.10. EMC Compliant Installation 19
10 Check the motor terminal box for correct Star or Delta
configuration where applicable
4.5. Motor Terminal Box Connections 16
11 Ensure wiring protection is providing, by installing a
suitable circuit breaker or fuses in the incoming supply line
4.3.2. Fuse / Circuit Breaker Selection
9.2. Rating Tables
15
37
12 Connect the power cables, especially ensuring the
protective earth connection is made
4.1. Connection Diagram
4.2. Protective Earth (PE) Connection
4.3. Incoming Power Connection
4.4. Motor Connection
14
15
15
16
13 Connect the control cables as required for the application 4.6. Control Terminal Wiring
4.10. EMC Compliant Installation
7. Analog and Digital Input Macro Configurations
7.8. Example Connection Diagrams
16
19
31
35
14 Thoroughly check the installation and wiring
15 Commission the drive parameters 5.1. Managing the Keypad
6. Parameters
20
22
1.3. Installation Following a Period of Storage
If the drive has not been powered, either unused or in storage, the DC Link Capacitors require reforming before power may be
connected to the drive. Refer to your local sales partner for information regarding the correct procedure.
