Version 2.00 | Optidrive ODE-3 User Guide | 7www.invertekdrives.com
General Information and Ratings
2
2. General Information and Ratings
This chapter contains information about the Optidrive E3 including how to identify the drive.
2.1. Identifying the Drive by Model Number
Each drive can be identified by its model number, as shown in the table below. The model number is on the shipping label and the
drive nameplate. The model number includes the drive and any options.
ODE - 3 - 1 2 0021 - 1 F 1 2
Product Family IP Rating 2 = IP20
X = IP66 Non Switched
Y = IP66 Switched
Generation Dynamic Brake
Transistor
1 = Not Fitted
4 = Internal Transistor
Frame Size Filter Type 0 = No Filter
F = Internal EMC Filter
Input Voltage 1 = 110 – 115 No. Of Input Phases
2 = 200 – 240
4 = 380 – 480
Output Current x 10
2.2. Drive Model Numbers
110 – 115V ± 10% - 1 Phase Input – 3 Phase 230V Output (Voltage Doubler)
Model Number
kW HP
Output Current
(A)
Frame Size
With Filter Without Filter
N/A ODE-3-110023-101# 0.5 2.3 1
N/A ODE-3-110043-101# 1 4.3 1
N/A ODE-3-210058-104# 1.5 5.8 2
200 – 240V ± 10% - 1 Phase Input – 3 Phase Output
Model Number
kW HP
Output Current
(A)
Frame Size
With Filter Without Filter
ODE-3-120023-1F1# ODE-3-120023-101# 0.37 0.5 2.3 1
ODE-3-120043-1F1# ODE-3-120043-101# 0.75 1 4.3 1
ODE-3-120070-1F1# ODE-3-120070-101# 1.5 2 7 1
ODE-3-220070-1F4# ODE-3-220070-104# 1.5 2 7 2
ODE-3-220105-1F4# ODE-3-220105-104# 2.2 3 10.5 2
N/A ODE-3-320153-104# 4.0 5 15 . 3 3
200 – 240V ± 10% - 3 Phase Input – 3 Phase Output
Model Number
kW HP
Output Current
(A)
Frame Size
With Filter Without Filter
N/A ODE-3-120023-301# 0.37 0.5 2.3 1
N/A ODE-3-120043-301# 0.75 1 4.3 1
N/A ODE-3-120070-301# 1.5 2 7 1
ODE-3-220070-3F4# ODE-3-220070-304# 1.5 2 7 2
ODE-3-220105-3F4# ODE-3-220105-304# 2.2 3 10.5 2
ODE-3-320180-3F4# ODE-3-320180-304# 4.0 5 18 3
ODE-3-320240-3F4# ODE-3-320240-304# 5.5 7. 5 24 3
ODE-3-420300-3F4# ODE-3-420300-304# 7. 5 10 30 4
ODE-3-420460-3F4# ODE-3-420460-304# 11 15 46 4
