Candy CDI 5653E10-S [14/56] Programme selection and special functions
![Candy CDI 5653E10-S [14/56] Programme selection and special functions](/views2/1762813/page14/bge.png)
PROGRAMME SELECTION
AND SPECIAL FUNCTIONS
(Use in conjunction with programme guide)
IMPORTANT
The dishwasher has two very practical
functions:
- the "recommended" programme
(which is set in the factory and is
ideal for full-load daily use) for quick
and accurate selection;
- the memory function which saves
the last programme used, so that if
you regularly use the same washing
cycle, you do not have to re-set the
programme every time, thereby
saving time and effort.
"DEGREE OF SOILING" buttons
These buttons allow to modify the wash
intensity, according to how dirty the dishes
are. The wash time and temperature will be
modified.
Pressing the button
+ the intensity of
wash will be increased, pressing the
button
– the intensity of wash will be
reduced and the wash time will be
remarkably shorter.
The combination of the buttons with the 4
main wash programmes enable to have 8
additional wash cycles.
IMPORTANT
When the dishwasher is switched on,
the "DEGREE OF SOILING" last used
will be indicated.
Programme settings
■ Open the door and place the dirty dishes
inside the appliance.
■ Press the "ON/OFF" button . The
display will show the "recommended"
programme, or the last programme
used.
■ To set another programme, press the
"PROGRAMME SELECTION" button
("PROGR.").
■ If you wish to choose the "DEGREE OF
SOILING", press the corresponding button.
■ If you wish to select an option, press the
option button (the corresponding indicator
light will light up).
The option button can be selected or
deselected WITHIN one minute of the
programme commencing.
■ Press the "START" button.
The length of the program will be shown on
the display alternating hours with minutes
[I.e.: 1 h (1 hour) / 25 (25 minutes)].
■ Close the door (after an audible signal
has sounded, the programme will start
automatically).
WHITIN one minute of the programme
commencing, another programme
can be selected, by pressing the
"PROGRAMME SELECTION" button
(it is also possible to change the
"DEGREE OF SOILING" setting).
“AUTOMATIC” programmes
The dishwasher is equipped with a dirt
sensor, able to analyse water murkiness
during all "AUTOMATIC" programme
phases (see programme list); thanks to
this sensor the washing cycle parameters
are automatically adapted to the real
quantity of dirt on dishes. Thus excellent
washing results are guaranteed while
optimising water and energy consumption.
"IMPULSE" programmes
The “IMPULSE” programmes use an
impluse washing technology, which reduces
consumption, noise and increases
performances.
IMPORTANT
The “intermittent” working of the
washing pump MUST NOT BE
considered a malfunction, it is a
characteristic of the impulse washing
so must be considered a normal
function of the programme.
14
