Lelit PL41PLUS [8/24] English
![Lelit PL41PLUS [8/24] English](/views2/1076348/page8/bg8.png)
Pagina 8
English
30. Once the drink has been suitably frothed, close the steam/hot water knob (4).
31. IMPORTANT: after you have frothed your milk, reopen the steam/hot water knob (4), position the steam
switch (13) on hot water, and lift the pump switch (22) up. When the water flows out of the steam tube (6),
close the steam/hot water knob (4), at the same time push the switch (22) down and re-position the switch
(13) on coffee mode. Clean carefully the steam/hot water tube (6). This operation is needed in order to
restore the water circuit inside the machine’s tubes.
Hot water:
32. Check that the water tank (1) contains enough water by looking at the water level indicator (20).
33. Press the on/off switch (11): the indicator light of the switch (11) will come on. Do this operation only if the
machine is off. If it’s on pass to the following point.
34. Position the lever switch (13) on hot water.
35. As soon as the PID’s display (21) shows the set temperature and the indicator light (14) goes off, the machine
is ready for use.
36. Open the steam/hot water knob (4) and lift the pump switch (22) up.
37. Hot water will flow out from the steam arm (6) immediately.
38. Once you have got the desired quantity of water, repress the switch (22) down and close the steam/water
knob (4).
39. After obtaining hot water from the arm (6), make sure that there is still water in the tank (1).
HOW TO SET THE BOILER’S TEMPERATURE BY MEANS OF THE PID:
The PID has been set by the producer of this machine on a temperature of 95°C. In order to change the temperature
please proceed as follows:
- press the button ; as soon as the display shows the writing “PRG” press the button ;
- as soon as the display shows the boiler’s temperature, help yourself with the buttons and in
order to set the desired temperature, starting from a min. of 80C° up to a max. of 130C°.
- after 3 sec. from pressing the last button, the inserted temperature is memorized and the display shows the
set temperature.
NB: if the temperature is set too high, once a coffee request is made, the display starts to flash.
USEFUL TIPS:
- The single cup filter basket (9) and the two cup filter basket (10) do not need to be washed after each use but
please check that the holes are not obstructed.
- For best results, we suggest warming the cups up on the cup warmer (2) which works only when the machine
is on.
- The PID (21) is already set by the producer on the right temperature for an excellent espresso. During heating
and coffee or water distribution, the temperature can oscillate (+/- 10/12°C). Also, a warning has been
inserted: after 108°C the PID’s display shows the temperature but intermittently; this is normal and it warns
the user that the coffee will not be good if made with such high temperature.
ROUTINE MAINTANCE AND PRECAUTIONS:
- It is recommended to clean, after each use, the steam arm (6) and the strainer holder (8) carefully.
- For cleaning it is recommended the use of a wet damp cloth.
- Do not leave the machine outdoor. And do not immerse the machine in water.
- The machine can be used only by adults and must be kept away from children.
- Do not wash strainer and strainer holder in dishwasher
- During normal functioning some parts of the appliance body may reach high temperatures: please handle
with care!
TECNICAL DATA:
Voltage: 230 V – 50 Hz
Power: 1250 W
Heating time: ca. 3 min.
Pump pressure: 15 bar
PID’s regulation: from 80°C up to 130°C
Water tank: 2,7 litres
Dimensions (HxLxD): 23x27x34 cm
Weight: 9 kg
To be operated with ground coffee
