Candy CSF 4590 E Инструкция по эксплуатации EN онлайн
Содержание
- The manufacturer following a policy of constant development and up dating of the product may make modifications without giving prior notice 2
- This manual contains sections of safety instructions operating instructions installation instructions and troubleshooting tips etc carefully reading it before using the dishwasher will help you to use and maintain the dishwasher properly 2
- A sound of click could be heard when the door is closed perfectly 5
- According to the soil level to choose the desired program by pressing program selection button 5
- At end of washing the time display will flash for 8 seconds while the buzzer sound but at the end of delayed washing no sound of the buzzer only the flash of the time display 5
- Daily wash in only 1 hour suitable for normal soiled dishes that are to be washed straight after a meal max 6 plate settings 5
- Draw out the lower and upper basket load the dishes and push them back it is commended that loading the lower basket first then the upper one the expensive and finer chinaware should not be put in 5
- For lightly soiled loads such as glasses crystal and fine china 5
- For lightly soiled loads such as plates glasses bowls and lightly soiled pans 5
- For the heaviest soiled loads such as pots pans casserole dishes and dishes that have been sitting with dried food on them for a while 5
- Insert the plug into the socket the power supply is 230v 50hz the specification of the socket is 250v 10a 5
- Press the on off button 5
- Press the on off button at the end of washing open the door of dishwasher after waiting 30 minutes 5
- Press the programme button to select the programme 5
- Press the start pause button to start washing 5
- Press this button to start automatic washing 5
- With a little force to ensure the door is properly closed 5
- Always use salt intended for use with dishwashers the salt container is located beneath the lower rack and should be filled as follows 6
- Contact your local water board for information on the hardness of your water supply 6
- If you are filling the container for the first time fill 2 3 of its volume with water 6
- If your model have not water softener you may skip this section 6
- Remove the lower basket and then unscrew and remove the cap from the salt container 6
- The dishwasher is designed to allow for adjusting the amount of salt consumed based on the hardness of the water used this is intended to optimize and customize the level of salt consumption so that the salt consumption could be set proceed as follows 6
- The hardness of the water varies from place to place if hard water is used in the dishwasher deposits will form on the dishes and utensils the appliances is equipped with a special softener that uses a salt specifically designed to eliminate lime and minerals from the water 6
- There is a ring on the container with an arrow on it see figure to the side if necessary rotate the ring in the anticlockwise direction from the setting toward the sign based on the hardness of the water being used it is recommended that adjustments should be made in accordance with the following schema 6
- Unscrew the cap from the salt container 6
- Dishwasher detergent is corrosive take care to keep it out of reach of children 7
- If the water isn t too hard you may also prevent the formation of deposits by adding detergent the amount of detergent needed can vary due to differences in water hardness to determine the water hardness in your area contact your local water utility or area water softening company the harder the water the more detergent you may need remember you should adjust the amount of detergent you use by small amounts until you find the correct amount 7
- Premis 9
- Coarse filter larger items such as pieces of bone or glass that could clog the drain are trapped in the coarse filter to remove an item caught in this filter gently squeeze the taps on the top of this filter and lift it out 10
- Fine filter this filter holds soil and food residue in the sump area and prevents it from being redeposit on the dishes during a cycle 10
- Main filter food and soil particles trapped by this filter are pulverized by a special jet on the lower spray arm and washed down the drain 10
- The filter prevent larger remnants of food or other objects from getting inside the pump this residue can occasionally clog up the filters the filter system consists of a filter cylinder coarse filter a flat main filter and a microfilter fine filter 10
- Never use a spray cleaner to clean the door panel for it could damage the door lock and electrical components it is not allowed to use the abrasive agent or some paper towel becauseof the risk of scratching or leaving spots on the stainless steel surface 11
- To clean the edge around the door you should use only a soft warm damp rag to prevent penetration of water into the door lock and electrical components do not use a spray cleaner of any kind also never use abrasive cleaners or scouring pads on the outer surfaces because they will scratch the finish some papers towels can also scratch or leave marks on the surface 11
- When you go on holiday it is recommened that you run a wash cycle with the dishwasher empty and then remove the plug from the socket turn off the water supply and leave the door of the appliance slightly ajar this will help the seals last longer and prevent odors from forming within the appliance 11
- A hose that attaches to a sink spray can burst if it is installed on the same water line as the dishwasher if your sink has one it is recommended thet the hose be disconnected and the hole plugged 12
- The safety supply hose consists of the double walls the hose s system guarantees its intervention by blocking the flow of water in case of the supply hose breaking and when the air space between the supply hose itself and the outer corrugated hose is full of water 12
- Connect the cold water supply hose to a threaded 3 4 inch connector and make sure that it is fastened tightly in place if the water pipes are new or have not been used for an extended period of time let the water run to make sure that the water is clear and free of impurities if this precaution is not taken there is a risk that the water inlet can get blocked and damage the appliance 13
- Dimensions mm 13
- Insert the drain hose into a drain pipe with a minimum diameter of 4 cm or let it run into the sink making sure to avoid bending or crimping it use the special plastic support that comes with the appliance the free end of the hose must be at a height between 40 and 100cm and must not be immersed in water 13
- Off position and slide the door latch to the left 15
