10
This dishwasher is designed for operation on an adequately wired individual 220~240VAC,50~60HZ. Use required fuse 10 amp.
Fused electrical supply is required-copper wire only. Time delay fuse or circuit breaker recommended and provide separate
circuit serving only this appliance. Outlet should be placed in adjacent cabinet.Make sure that plug on the appliance remains
eccessible after installation.
After making sure that the voltage and the frequency values for the current in the home
correspond to those on the rating plate and that the electrical system is sized for the
maximum voltage on the rating plate, insert the plug into an electrical socket which is
earthed properly. If the electrical socket to which the appliance must be connected is not
appropriate for the , replace the socket, installed by qualified electrician, rather then
using an adaptors or the like as they could cause overheating and burns.
plug
Remove the power cord plug from the wall receptacle.
Disconnect Unicouple from faucet adapter.
2
1
A hose that attaches to a sink spray can burst if it is installed on the same water line as the dishwasher. If your sink has one, it is
recommended thet the hose be disconnected and the hole plugged.
Pull The safety supply hoses completely out from storage compartment located at rear of dishwasher.
Turn water fully on before starting the dishwasher.
1
Tighter the screws of the safety supply hose to the faucet with thread 3/4inch.
The safety supply hose consists of the double walls. The hose's system guarantees its intervention by blocking the flow of water
in case of the supply hose breaking and when the air space between the supply hose itself and the outer corrugated hose is full
of water.
Turn off the water.
Release the water pressure by depressing the pressure release button. This relieves water pressure and protects you, and the
room, from severe splashing.
Unscrew The safety supply hose from the faucet..
3
2
1
2
3
The appliance must be connected to the water mains using new hose-sets.
The old hose-sets should not be reused.
Water pressure must be between 0,04 MPa and 1 MPa. If the pressure is below theminimum
consult our Service Department for advice.
