Troubleshooting by Indication on the Remote Control ESiEN09-06
186 Troubleshooting
3.2 “
A1
” AHU: PC Board Defect
Remote Control
Display
A1
Applicable
Models
All AHU models
Method of
Malfunction
Detection
Check data from E²PROM.
Malfunction
Decision
Conditions
When data could not be correctly received from the E²PROM
E²PROM: Type of nonvolatile memory. Maintains memory contents even when the power
supply is turned off.
Supposed
Causes
Defect of AHU PC board
Troubleshooting
YES
Caution
Does the
system return to
normal?
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Turn power supply OFF, then
power ON again.
Replace the AHU PC board.
(V2777)
NO
The AHU PC board is normal.
External factor other than
malfunction (for example,
noise etc.).
ESiEN09-06.pdf 194 2/16/2010 4:42:51 PM
