EN 9
REVERSING THE OPENING OF THE DOORS
PRODUCT DIMENSIONS AND BUILT-IN COMPARTMENT
Remove the upper plate and
hinge by screw driver.
Remove the right bottom hinge
and left plastic plugs, and refit
them onto the opposite side.
Remove the upper door.
Reassemble the doors and hinges
workings from bottom to top, from 1-4.
Remove the middle hinge and its
connecting pin underneath
.
Remove the bottom door.
Use the opposite hinge and cover
and fit into the left bottom
7
812mm 812mm6035
1769mm
50
1771 1775
