Si-71A Electric Function Parts
Explanation of Function Operation 57
RY140KY1 RY140KTAL
M1C Compressor JT170BC-YE JT170BC
J1HC Crank Case Heater 33W
S1PH Pressure Switch for Maintaining
High Pressure
ACB-DB82
OFF : 30
+0
-1
(kg/cm²G)
ON : 22
±
1.5 (kg/cm²G)
S1LP Pressure Switch for Low
Pressure Control
20PS-1164-1
OFF : –23
±
15 (cmHg)
ON : 0.5
±
0.3 (kg/cm²G)
K1M Magnetic Switch HOE-20F-TRA1 HOE-35F-TRA1
F1C Overcurrent Relay 15A 28A
M1F Outdoor Unit Fan (Upper) 100W
M2F Outdoor Unit Fan (Lower) 65W
Q1L
Q2L
Outdoor Unit Fan Motor Safety
Thermostat
OFF : 135
±
5°C
ON : Below 120°C
C1R Capacitor for M1F 6
µ
F
C2R Capacitor for M2F 6
µ
F
A1P Outdoor Unit Control PC Board EC9641
A2P Outdoor Control PC Board
(Models for the FJ Type Only)
—
R1T Thermistor (for Outdoor Air) ST9303
R2T Thermistor (for Heat Exchanger) ST8604A
R3T Thermistor (for Discharge Pipe) ST8606
T1R Transformer TR21H16R2 TR21M16R2
Y1R 4-way Changeover Valve VH40100
Y1E Electronic Expansion Valve EKV30D36
EKV-MOZS107BO (Coil)
K1S Starting Relay —
C3R,
C4R
M1C Capacitor —
C5R Starting Capacitor —
