ED40-437 Power Supply and Nomenclature
FDMG-AV1(S) Series 3
2. Power Supply and Nomenclature
2.1 Power Supply
2.1.1 50Hz
2.1.2 50Hz (For Thailand)
Note: 1. * : New Model or Changed Model
2. Power Supply Intake : Outdoor Unit
2.2 Nomenclature
Indoor Unit
Outdoor Unit
Indoor Unit Outdoor Unit Power Supply
FDMG71AV1 ∗ RG71AV1 ∗
1 phase 220–240V (2 wires)
FDMG100AV1 ∗ R100FUV1
FDMG71AV1 ∗ RG71AY1 ∗
3 phase 380–415V (4 wires)
FDMG100AV1 ∗ R100FUY1
FDMG125AV1 ∗ R125FUY1
FDMG140AV1 ∗ RG140AY1 ∗
FDMG180AV1 ∗ RG180AY1 ∗
Indoor Unit Outdoor Unit Power Supply
FDMG71AV1S ∗ RG71AV1S ∗
1 phase 220V (2 wires)
FDMG100AV1S ∗ R100FUV1S
FDMG71AV1S ∗ RG71AY1S ∗
3 phase 380V (4 wires)
FDMG100AV1S ∗ R100FUY1S
FDMG125AV1S ∗ R125FUY1S
FDMG140AV1S ∗ RG140AY1S ∗
FDMG180AV1S ∗ RG180AY1S ∗
Duct Connection Middle Static Pressure Type
FDM : Cooling Only
DIT Products
Capacity Index
Indicates Major Design Category
Power Supply Symbol
V1 : 1φ 220~240V 50Hz
For Thailand
V171FDM AG
S
Outdoor Unit
R : Cooling Only
DIT Products
Capacity Index
Indicates Major Design Category
Power Supply Symbol
V1 : 1φ 220~240V 50Hz
Y1 : 3φ 380~415V 50Hz
For Thailand
R
V171 AG
S
