Specification ED40-437
6 FDMG-AV1(S) Series
Note: ∗1. The above data are based on the following conditions.
∗2. Capacities are gross, including a deduction for cooling for indoor fan motor heat.
∗3. Please see fan characteristic documents in detail.
Model
Indoor Unit FDMG140AV1 FDMG180AV1
Outdoor Unit RG140AY1 RG180AY1
∗1 Cooling Capacity
∗2 (1)/(2)/(3)
kW 14.5 / 14.2 / 12.3 17.2 / 16.8 / 15.1
Btu/h 49,400 / 48,400 / 42,000 58,700/ 57,500 / 51,600
kcal/h 12,500 / 12,200 / 10,600 14,700 / 14,400 / 13,000
Indoor Unit FDMG140AV1 FDMG180AV1
Dimensions H×W×D mm 305×1,550×680 305×1,900×680
Coil
Type Cross Fin Coil
Row×Stages×Fin Pitch 3×12×1.75 3×12×1.75
Face Area m² 0.340 0.428
Fan
Type Sirocco Fan
Motor Output W 225 225
Rated Air Flow ∗3 m³/min 42 42
Rated Ext. Static Pressure ∗3 mmH
2
O8.0 9.8
Mass (Weight) kg 52 58
Piping Connections
Liquid mm φ 9.5 (Flare) φ 9.5 (Flare)
Gas mm φ 19.1 (Flare) φ 19.1 (Flare)
Drain mm 3 / 4 B (O.D.φ27.2 I.D.φ21.6) 3 / 4 B (O.D.φ27.2 I.D.φ21.6)
Remote Controller
Wired KRC47-1 KRC47-2 KRC47-4 KRC47-1 KRC47-2 KRC47-4
Wireless — —
Outdoor Unit RG140AY1 RG180AY1
Color Ivory
Dimensions H×W×D mm 1,345×880×370 1,345×880×370
Coil
Type Cross Fin Coil
Row×Stages×Fin Pitch 2×60×2.0 2×60×2.0
Face Area m² 1.088 1.088
Comp.
Model JT170BC–YE JT200B–YE
Type Hermetically Sealed Scroll Type
Motor Output kW 4.5 4.5
Fan
Model P45J11S P45J11S
Type Propeller
Motor Output W 64+56 64+56
Air Flow Rate m³/min 101 101
Mass (Weight) kg 113 114
Piping Connections
Liquid mm φ 9.5 (Flare) φ 9.5 (Flare)
Gas mm φ 19.1 (Flare) φ 19.1 (Flare)
Drain mm φ 26.0 (Hole) φ 26.0 (Hole)
Safety Devices
Thermal Protector for Compressor, Outdoor Fan Motor and Indoor
Fan Motor. High Pressure Switch. Low Pressure Switch. Over
Current Relay (Compressor). Reverse Phase Protector. Fuse.
Capacity Step % 100–0 100–0
Refrigerant Control Capillary Tube
Ref.
Piping
Standard Length m 5 5
Max. Length m 50 (Equivalent Length 70m) 50 (Equivalent Length 70m)
Max. Height Difference
m30 30
Refrigerant
Model R22 R22
Charge kg 2.9 (Factory Charge for 5m) 2.8 (Field Charge for 5m)
Ref. Oil
Model Refer to the name plate of compressor
Charge L 1.6 1.6
Drawing No. 3D048714
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length Hz, Volts Standard
(1)
Indoor:
Outdoor:
27°C(81°F)DB, 19.5°C(67°F)WB
35°C(95°F)DB, 24°C(75°F)WB
5m (Horizontal)
50Hz, 220–240V
(380–415V)
—
(2)
Indoor:
Outdoor:
27°C(81°F)DB, 19.0°C(66°F)WB
35°C(95°F)DB, 24°C(75°F)WB
5m (Horizontal)
50Hz, 220–240V
(380–415V)
—
(3)
Indoor:
Outdoor:
29°C(84°F)DB, 19.0°C(66°F)WB
46°C(115°F)DB, 24°C(75°F)WB
7.5m (Horizontal)
50Hz, 240V
(415V)
SSA 385/386
