![Daikin FXSN112A2VEB [71/80] Configuration](/views2/1767442/page71/bg47.png)
19 | Configuration
Installer and user reference guide
71
FXSN50~112A2VEB
CO₂ Conveni-Pack: indoor unit
4P602817-1A – 2020.05
INFORMATION
▪ The fan speed of the indoor unit is preset to ensure the standard external static
pressure.
▪ To set a higher or lower external static pressure, reset the initial setting with the
user interface.
User interface
Check the indoor unit setting:—/C2 of mode 11(21) must be set to 01.
Change—/C2 according to the external static pressure of the duct to be connected
as in the table below.
External static pressure
(1)
M SW/C1 —/C2 Class
50 71 112
13(23) 6 01 30 40 50
02 — — —
03 30 — —
04 40 40 —
05 50 50 50
06 60 60 60
07 70 70 70
08 80 80 80
09 90 90 90
10 100 100 100
11 110 110 110
12 120 120 120
13 130 130 130
14 140 140 140
15 150 150 150
Time to clean air filter
This setting must correspond with the air contamination in the room. It determines
the interval at which the TIME TO CLEAN AIR FILTER notification is displayed on
the user interface. When using a wireless user interface, you must also set the
address (see the installation manual of the user interface).
If you want an interval of…
(air contamination)
Then
(1)
M SW/C1 —/C2
±2500h (light) 10(20) 0 01
±1250h (heavy) 02
No notification 3 02
(1)
Field settings are defined as follows:
• M: Mode number – First number: for group of units – Number between brackets: for individual unit
• SW: Setting number / C1: First code number
• —: Value number / C2: Second code number
• : Default
