ASUS PRIME A520M-K
1-5
1.2.2 Rear panel connectors
Ethernet port
Speed
LED
Activity Link
LED
Activity/Link LED Speed LED
Status
Description Status
Description
Off
No link Off
10Mbps connection
Orange
Linked Orange
100Mbps connection
Orange (Blinking)
Data activity Green
1Gbps connection
Orange (Blinking
then steady)
Ready to wake
up from S5 mode
1 2
6 7 8 6 9
3 4 5
Ethernet port LED indications
1. PS/2 Keyboard/Mouse combo port. This port is for a PS/2 keyboard or mouse.
2. Video Graphics Adapter (VGA) port. This 15-pin port is for a VGA monitor or other
VGA-compatible devices.
3. Ethernet port. This port allows Gigabit connection to a Local Area Network (LAN)
through a network hub. Refer to the table below for the Ethernet port LED indications.
4. Line In port (light blue). This port connects the tape, CD, DVD player, or other audio
sources.
5. Line Out port (lime). This port connects a headphone or a speaker. In 4-channel,
5.1-channel, and 7.1-channel congurations, the function of this port becomes Front
Speaker Out.
6. USB 3.2 Gen 1 (up to 5Gbps) ports. These 9-pin Universal Serial Bus (USB) ports
connect to USB 3.2 Gen 1 devices.
7. HDMI
TM
port. This port is for a High-Denition Multimedia Interface (HDMI
TM
)
connector, and is HDCP compliant allowing playback of HD DVD, Blu-ray, and other
protected content.
8. USB 2.0 ports. These 4-pin Universal Serial Bus (USB) ports are for USB 2.0 devices.
