vi
PRIME H570-PLUS specifications summary
CPU
Intel
®
Socket LGA1200 for 11
th
Gen Intel
®
Core™ processors & 10
th
Gen
Intel
®
Core™, Pentium
®
Gold and Celeron
®
Processors*
Supports Intel
®
14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0 and Intel
®
Turbo Boost Max
Technology 3.0**
* Refer to www.asus.com for CPU support list.
** Intel
®
Turbo Boost Max Technology 3.0 support depends on the CPU types.
Chipset
Intel
®
H570 Chipset
Memory
4 x DIMM, Max. 128GB, DDR4 4600(OC)/4400(OC)/4266(OC)/4000(OC)/
3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200(OC)/2933/2800/2666/
2400/2133 MHz Non-ECC, Un-buffered memory*
Dual Channel Memory Architecture
Supports Intel
®
Extreme Memory Prole (XMP)
ASUS OptiMem
* 11
th
Gen Intel
®
processors support 2933/2800/2666/2400/2133 natively.
* 10
th
Gen Intel
®
Core™ i7/ i9 processors support 2933/2800/2666/2400/2133 natively,
others will run at the maximum transfer rate of DDR4 2666MHz.
*
Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and
memory frequency support depends on the CPU types.
Graphics
1 x DisplayPort 1.2**
1 x HDMI
TM
1.4/2.0***
* Graphics specifications may vary between CPU types.
** For Intel
®
11
th
& 10
th
Gen processors, support DisplayPort 1.4 with max.
resolution of 4096 x 2304 @60Hz. Please refer to www.intel.com for any update.
***Only Intel
®
11
th
Gen processors support HDMI™ 2.0 with max. resolution
of 4K@60Hz, others will only support HDMI™ 1.4 with max. resolution of
4K@30Hz. Please refer to www.intel.com for any updates.
Expansion Slots
Intel
®
11
th
& 10
th
Gen Processors
1 x PCIe 4.0/3.0 x16 slot
- Intel
®
11
th
Gen processors support PCIe 4.0 x16
- Intel
®
10
th
Gen processors support PCIe 3.0 x16
Intel
®
H570 Chipset
1 x PCIe 3.0 x16 slot (max. at x4 mode)
3 x PCIe 3.0 x1 slots
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
1 x PRIME H570-PLUS motherboard
Cables
2 x SATA 6Gb/s cables
Miscellaneous
1 x M.2 Rubber Package
1 x I/O Shield
1 x M.2 SSD screw package
1 x M.2 Key E screw package
Application DVD
1 x Support DVD
Documentation
1 x User manual
If any of the above items is damaged or missing, contact your retailer.
