vii
PRIME H570-PLUS specifications summary
Storage
Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
Intel
®
11
th
Gen Processors
M.2_1 slot (Key M), type 2242/2260/2280/22110
- Only Intel
®
11
th
Gen processors support PCIe 4.0 x4 mode, this slot will
be disabled for other CPUs
Intel
®
H570 Chipset
M.2_2 slot (Key M), type 2242/2260/2280/22110
(supports PCIe 3.0 x4 & SATA modes)
6 x SATA 6Gb/s ports
Intel
®
Optane™ Memory Ready
* Raid function for PCIe mode SSD in Intel
®
Rapid Storage Technology is
available with either
1. Intel
®
SSDs installed in both CPU-attached and PCH-attached slots, or
2. any other 3rd party SSDs installed in PCH-attached slots.
* To enable Intel
®
Optane™ Memory (Hybrid Storage device), it must be installed
in PCH-attached slots with Intel
®
Rapid Storage Technology.
* M.2_2 shares bandwidth with SATA6G_2. When a device in SATA mode is
installed on the M.2_2 socket, SATA6G_2 port cannot be used.
Ethernet
Intel
®
I219-V 1Gb Ethernet
ASUS LANGuard
USB
Rear USB (Total 7 ports)
2 x USB 3.2 Gen 2 ports (2 x Type-A)
1 x USB 3.2 Gen 2 port (1 x USB Type-C
®
)
4 x USB 2.0 ports (4 x Type-A)
Front USB (Total 8 ports)
2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
Audio
Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192kHz playback
Audio Features
- Audio Shielding
- Premium Japanese audio capacitors
- Dedicated audio PCB layers
* A chassis with an HD audio module in the front panel is required to support 7.1
Surround Sound audio output.
Back Panel I/O Ports
2 x USB 3.2 Gen 2 ports (2 x Type-A)
1 x USB 3.2 Gen 2 port (1 x USB Type-C
®
)
4 x USB 2.0 ports (4 x Type-A)
1 x DisplayPort
1 x HDMI
TM
port
3 x Audio jacks
1 x PS/2 Keyboard/Mouse combo port
1 x Intel
®
I219-V 1Gb Ethernet port
(continued on the next page)
