ASUS PRIME B460-PLUS

1-5

• ATXpowerbutton/soft-offbutton(2-pinPWR_SW)

Thisheaderisforthesystempowerbutton.Pressingthepowerbuttonturnsthe

system on or puts the system in sleep or soft-off mode depending on the operating

systemsettings.Pressingthepowerswitchformorethanfoursecondswhilethe

systemisONturnsthesystemOFF.

• Resetbutton(2-pinRESET)

This 2-pin header is for the chassis-mounted reset button for system reboot without

turning off the system power.

• Chassisintrusionheader(2-pinCHASSIS)

This header is for a chassis-mounted intrusion detection sensor or switch. Connect one

end of the chassis intrusion sensor or switch cable to this header. The chassis intrusion

sensororswitchsendsahigh-levelsignaltothisconnectorwhenachassiscomponent

isremovedorreplaced.Thesignalisthengeneratedasachassisintrusionevent.

1.2.2 Rear panel connectors

1 2

6 8 97 10

3 4 5

1. PS/2 keyboard/mouse combo port.ThisportisforaPS/2mouseorkeyboard.

2. Video Graphics Adapter (VGA) port.This15-pinportisforaVGAmonitororother

VGA-compatibledevices.

3. Ethernet port.ThisportallowsGigabitconnectiontoaLocalAreaNetwork(LAN)

throughanetworkhub.RefertothetablebelowfortheEthernetportLEDindications.

Ethernet port

Speed

LED

Activity Link

LED

Activity/Link LED Speed LED

Status Description Status Description

Off Nolink OFF 10Mbpsconnection

Orange Linked ORANGE 100Mbpsconnection

Orange(Blinking) Dataactivity GREEN 1Gbps connection

Orange(Blinking

then steady)

Ready to wake

upfromS5mode

Ethernet port LED indications
