42
PRIME/PRO/ProArt/TUF GAMING Intel 400 Series BIOS Manual
SMART Self Test
S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) is a monitoring system
that shows a warning message during POST (Power-on Self Test) when an error occurs in
the hard disks.
Configuration options: [On] [Off]
SATA6G_1(Gray) - SATA6G_6(Gray)
The items in this submenu may vary according to your motherboard.
SATA6G_1(Gray) - SATA6G_6(Gray)
This item allows you to enable or disable the selected SATA port.
Configuration options: [Disabled] [Enabled]
SATA6G_1 - SATA6G_6 Hot Plug
These items appears only when the SATA Mode Selection is set to [AHCI] and allows
you to enable or disable SATA Hot Plug Support.
Configuration options: [Disabled] [Enabled]
1.6.6 PCH-FW Configuration
This item allows you to configure the firmware TPM.
PTT
This item allows you to enable or disable PTT in SkuMgr.
Configuration options: [Disabled] [Enabled]
