vii
ROG STRIX B550-I GAMING specifications summary
USB
Rear USB (Total 6 ports)
4 x USB 3.2 Gen 2 ports (3 x Type-A + 1 x USB Type-C
®
)
1 x USB 2.0 port (Type-A)
1 x USB 2.0 port (1 x audio USB Type-C
®
)
Front USB (Total 5 ports)
1 x USB 3.2 Gen 2 front panel connector (supports USB Type-C
®
)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports
Audio
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC
S1220A
- Impedance sense for front and rear headphone outputs
- Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR
recording input
- Supports up to 32-Bit/192kHz playback*
Audio Features:
- Audio Shielding
- Dual OP Amplifiers
- LED-illuminated audio jacks
- Rear audio USB Type-C
®
port
- Premium Japanese audio capacitors
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
7.1-Channel audio.
Back Panel I/O Ports
4 x USB 3.2 Gen 2 ports (3 x Type-A + 1 x USB Type-C
®
)
1 x USB 2.0 port
1 x USB 2.0 port (1 x audio USB Type-C
®
)
1 x DisplayPort
1 x HDMI™ port
1 x ASUS Wi-Fi Module
1 x BIOS FlashBack™ button
1 x Intel
®
I225-V 2.5Gb Ethernet port
3 x LED-illuminated audio jacks
Internal I/O connectors
Fan and cooling related
1 x 4-Pin AIO_Pump header
1 x 4-Pin CPU Fan header
1 x 4-Pin Chassis Fan header
1 x VRM Heatsink Fan header
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
(continued on the next page)
