ROG STRIX B550-E GAMING BIOS Manual

VDDCR SOC Switching Frequency

Use the <+> or <-> to adjust the value. The values range from 200 to 350 with an

interval of 50.

DO NOT remove the thermal module. The thermal conditions should be monitored.

The following item appears only when you set the VDDCR SOC Switching Frequency to

[Manual].

Fixed VDDCR SOC Switching Frequency (KHz)

This item allows you to set a higher frequency for a quicker transient response speed.

Use the <+> and <-> keys to adjust the value. The values range from 300KHz to

600KHz with a 50KHz interval.

VDDCR SOC Power Phase Control

Conguration options: [Optimized] [Extreme] [Manual]

The following item appears only when the VDDCR SOC Power Phase Control is set to

[Manual].

Manual Adjustment

This item allows you to set the response time, selecting [Regular] will

result in longer reaction times.

Conguration options: [Regular] [Medium] [Fast] [Ultra Fast]

VDDCR CPU Voltage

Conguration options: [Auto] [Manual] [Offset mode]

The following item appears only when you set the VDDCR CPU Voltage to [Manual].

VDDCR CPU Voltage Override

Conguration options: [Auto] [0.750] - [2.000]

The following items appear only when you set the VDDCR CPU Voltage to [Offset mode].

VDDCR CPU Offset Mode Sign

[+] To offset the voltage by a positive value.

[–] To offset the voltage by a negative value.

VDDCR CPU Offset Voltage

Conguration options: [Auto] [0.00625] - [-0.40000/+0.50000]

VDDCR SOC Voltage

Conguration options: [Auto] [Manual] [Offset mode]

The following item appears only when you set the VDDCR SOC Voltage to [Manual].
