Asus ROG STRIX B460-H GAMING [10/58] M _1 pcie 3 x4 sata
![Asus ROG STRIX B460-H GAMING [10/58] M _1 pcie 3 x4 sata](/views2/1769530/page10/bga.png)
x
Connectors with shared bandwidth
A
B
A
A
B
C
C
DDR4 DIMM_B1 (64bit, 288-pin module)
DDR4 DIMM_B2* (64bit, 288-pin module)
DDR4 DIMM_A1 (64bit, 288-pin module)
DDR4 DIMM_A2* (64bit, 288-pin module)
AIO_PUMP
CHA_FAN2
CHA_FAN1
CPU_FAN
CPU_OPT
BOOT
VGA
DRAM
CPU
M.2_1(SOCKET3)
M.2_1(SOCKET3)
M.2_2(SOCKET3)
M.2(WIFI)
RGB_HEADER
ADD_GEN2
AURA
PANEL
AAFP
CLRTC
128Mb
BIOS
SATA6G_1SATA6G_2SATA6G_3SATA6G_4SATA6G_5SATA6G_6
EATX12V
LGA1200
EATXPWRU32G1_78
Intel
®
B460
BATTERY
HDMI
_DP
PCIEX1_1
2280 2260 2242
M.2_2(SOCKET3)
PCIE SATA IRST
X4
X
V
PCIE SATA IRST
X4
V
X
2280
22110
2260 2242
PCIEX1_2
PCIEX1_3
PCIEX16_2
PCIEX16_1
USB_E34
USB_E12
TB_HEADER
U32G1_34
U32G1_56
U32G2X2_EC1
AUDIO
LAN_U32G1_12
Configuration
1 2
A
PCIEX16_2 x4 x2
PCIEX1_1 - x1
PCIEX1_3 - x1
Configuration 1
B
PCIEX1_2 x1 -
M.2 (Key E) - v
Configuration 1 2
C
M.2_1 PCIe 3.0 x4 SATA
SATA6G_1 v -
• The PCIEX16_2 shares bandwidth with the PCIEX1_1 and PCIEX1_3. When
PCIEX16_2 runs x4 mode, PCIEX1_1 and PCIEX1_3 will be disabled. The
PCIEX16_2 will run x2 mode when PCIEX1_1 or PCIEX1_3 is occupied.
• The PCIEX1_1 and PCIEX1_3 share bandwidth with PCIEX16_2. The PCIEX1_2
shares bandwidth with M.2 slot (Key E).
• When M.2_1 is operating in SATA mode, SATA6G_1 will be disabled.
