Asus DSL-AC88U Annex B [7/66] Power adapter specifications
![Asus DSL-AC88U Annex B [7/66] Power adapter specifications](/views2/1771322/page7/bg7.png)
7
6
E-WAN LED
O: No Ethernet connection.
ON: Connection to Ethernet.
7
LAN LED
O: No power or no physical connection.
On: Has physical connection to a local area network (LAN).
8
USB LED
O: No power or no physical connection with a USB device.
On: Has physical connection with a USB device.
9
USB 3.0 port
Insert a USB 3.0/2.0 device such as USB hard disk or USB flash drive into the
port.
Insert your iPad’s USB cable into the port to charge your iPad.
10
LED Button
This button turns on/off the LED indicators.
11
Wi-Fi Button
This button enables or disables Wi-Fi.
Use only the power adapter that came with your package. Using
other adapters may damage the device.
DC Power adapter
DC output 19V with max. 1.75A current
Operating
Temperature
0~40
o
C
Storage Temperature 0~70
o
C
Operating Humidity
50~90%
Storage Humidity 20~90%
Power adapter specications:
