Asus P10S-V/4L — обзор внутренних соединений и возможностей RAID для SATA [43/140]

Содержание

• E13690 revised edition v4 december 2017 p.2
• Contents p.3
• Chapter 2 hardware information p.3
• Chapter 1 product introduction p.3
• Contents p.4
• Chapter 4 bios setup p.4
• Chapter 3 powering up p.4
• Chapter 5 raid configuration p.5
• Contents p.5
• Contents p.6
• Chapter 6 driver installation p.6
• Appendix p.6
• Notices p.7
• Federal communications commission statement p.7
• D é claration de conformit é de innovation sciences et d é veloppement é conomique canada ised p.7
• Compliance statement of innovation science and economic development canada ised p.7
• Australia statement notice p.8
• Safety information p.9
• Operation safety p.9
• Electrical safety p.9
• Typography p.10
• Conventions used in this guide p.10
• Command p.10
• P10s v 4l specifications summary p.11
• Chapter 1 product introduction p.13
• Welcome p.14
• Package contents p.14
• Turbo boost p.15
• Special features p.15
• Serial number label p.15
• Product highlights p.15
• P10s v 4l p.15
• Latest processor technology p.15
• Hyper threading p.15
• Ddr4 memory support p.15
• Innovative asus features p.16
• I210at lan solution p.16
• Enhanced intel speedstep technology eist p.16
• Asus mio audio card p.16
• Asus fan speed technology p.16
• Usb 3 technology p.16
• Usb 2 technology p.16
• Temperature fan and voltage monitoring p.16
• Serial ata iii technology p.16
• Pci express 3 p.16
• Chapter 2 hardware information p.17
• Take note of the following precautions before you install motherboard components or change any motherboard settings p.18
• Chapter 2 hardware information p.18
• Before you proceed p.18
• Screw holes p.19
• Placement direction p.19
• Motherboard overview p.19
• Motherboard layout p.20
• Layout contents p.21
• Central processing unit cpu p.23
• Asus p10s v 4l p.23
• Toinstallthecpu p.23
• Themotherboardcomeswithasurfacemountlga1151socketdesignedfortheintel p.23
• Locatethecpusocketonthemotherboard p.23
• Installing the cpu p.23
• E3 1200v5andintel p.23
• Core i3processor p.23
• Toinstallthecpuheatsinkandfan p.26
• Theinte p.26
• Push down two fasteners at a time in adiagonalsequencetosecurethe heatsink and fan assembly in place p.26
• Placetheheatsinkontopoftheinstalled cpu makingsurethatthefourfasteners match the holes on the motherboard p.26
• Lga1151processorrequiresaspeciallydesignedcpuheatsinktoensure optimum thermal condition and performance p.26
• Installing the cpu heatsink p.26
• Chapter 2 hardware information p.26
• Uninstalling the cpu heatsink and fan p.27
• Installing the cpu heatsink in rack p.28
• Memory configurations p.29
• System memory p.29
• Overview p.29
• Removing a dimm from a single clip dimm socket p.30
• Installing a dimm on a single clip dimm socket p.30
• Installing an expansion card p.31
• Expansion slots p.31
• Configuring an expansion card p.31
• Standard interrupt assignments p.32
• Interrupt assignments p.32
• Pci slot p.33
• Pci express x8 slot x4 link p.33
• Pci express x16 slot x16 link p.33
• Installing the audio card p.34
• Onboard leds p.35
• Jumpers p.37
• Connectors p.40
• Rear panel connectors p.40
• Lan port led indications p.40
• Q code table p.41
• Continued on the next page p.41
• Asus p10s v 4l p.41
• Chapter 2 hardware information p.42
• Internal connectors p.43
• Theseconnectorsarefortheatxpowersupplyplugs thepowersupplyplugsare designedtofittheseconnectorsinonlyoneorientation findtheproperorientationand pushdownfirmlyuntiltheconnectorscompletelyfit p.48
• Chapter 2 hardware information p.48
• Atx power connectors 24 pin eatxpwr1 8 pin eatx12v1 p.48
• Chapter 3 powering up p.53
• Starting up for the first time p.54
• Using the os shut down function p.55
• Using the dual function power switch p.55
• Powering off the computer p.55
• Chapter 3 powering up p.56
• Chapter 4 bios setup p.57
• Recovering the bios from a usb flash drive p.58
• Managing and updating your bios p.58
• Asus crashfree bios 3 utility p.58
• Up down left right switch enter choose q exit p.59
• New platform platform p10s v 4l version 0206 build date 08 01 2015 p.59
• Current platform platform p10s v 4l version 0200 build date 07 20 2015 p.59
• Asus tek ezflash utility p.59
• Asus ezflash utility p.59
• Updating the bios file p.60
• Bupdater utility p.60
• Theutilityverifiesthefile thenstartsupdatingthebiosfile p.61
• The utility returns to the dos prompt after the bios update process is completed p.61
• Rebootthesystemfromtheharddiskdrive p.61
• Do not shut down or reset the system while updating the bios to prevent system boot failure p.61
• Asus p10s v 4l p.61
• Bios setup program p.62
• Menu bar p.63
• Bios menu screen p.63
• Submenu items p.64
• Scroll bar p.64
• Pop up window p.64
• Navigation keys p.64
• Menu items p.64
• General help p.64
• Configuration fields p.64
• System time xx xx xx p.65
• System date day xx xx xxxx p.65
• Main menu p.65
• The advanced menu items allow you to change the settings for the cpu and other system devices p.66
• Chapter 4 bios setup p.66
• Advanced menu p.66
• Vt d enabled p.67
• Trusted computing p.67
• System agent sa configuration p.67
• Security device support enabled p.67
• Device select auto p.67
• Configuration p.67
• Chipset configuration p.67
• Dmi opi configuration p.68
• Above 4gb mmio bios assignment disabled p.68
• Peg port configuration p.69
• Memory configuration p.70
• Pci express configuration p.71
• Pch io configuration p.71
• Serial irq mode continuous p.72
• High precision timer enabled p.72
• Clkrun logic enabled p.72
• Usb configuration p.72
• Vga priority offboard device p.74
• Serr generation disabled p.74
• Perr generation disabled p.74
• Pcie slot oprom option p.74
• Pci pcie subsystem settings p.74
• Pci latency timer 32 pci bus clocks p.74
• Load rt32 image enabled p.74
• Xhci hand off disabled p.75
• Usb configuration p.75
• Platform configuration p.75
• Legacy usb support enabled p.75
• Port 60 64 emulation enabled p.76
• Mass storage devices p.76
• Device reset time out 20 sec p.76
• Device power up delay auto p.76
• Usb transfer time out 20 sec p.76
• Usb mass storage driver support enabled p.76
• Usb hardware delays and time outs p.76
• Super io configuration p.77
• Onboard lan configuration p.77
• Intel lan2 lan3 lan4 enable enabled p.77
• Intel lan1 enable enabled p.77
• Intel lan rom type pxe p.77
• Intel lan rom type disabled p.77
• Serial port console redirection p.78
• Serial port 1 configuration p.78
• Console redirection settings p.78
• Console redirection enabled p.78
• Serial port for out of band management p.80
• Legacy console redirection settings p.80
• Console redirection disabled p.80
• Windows emergency management services ems p.80
• Enable hibernation enabled p.81
• Console redirection settings p.81
• Acpi sleep state s3 suspend to ram p.81
• Acpi settings p.81
• Smart settings p.82
• Smart self test enabled p.82
• Restore ac power loss last state p.82
• Power on by rtc disabled p.82
• Power on by ring disabled p.82
• Power on by pcie disabled p.82
• Power on by pci disabled p.82
• Whea support enabled p.83
• Whea configurations p.83
• Cpu configuration p.83
• Active processor cores all p.84
• Intel virtualization technology enabled p.84
• Hardware prefetcher enabled p.84
• Cpu aes enabled p.84
• Boot performance mode turbo performance p.84
• Adjacent cache line prefetch enabled p.84
• Intel r speedstep tm enabled p.85
• Hardware p states hwp disabled p.85
• Ctdp bios control disabled p.85
• Cpu c states enabled p.85
• Configurable tdp lock disabled p.85
• Configurable tdp boot mode nominal p.85
• Package c state limit auto p.86
• Intel txt lt support disabled p.86
• Cstate pre wake enabled p.86
• Cfg lock enabled p.86
• Sata configuration p.87
• Sata mode selection ahci p.87
• Sata controller s enabled p.87
• Software feature mask configuration p.88
• Sata port 1 sata port 2 sata port 3 sata port 4 sata port 5 sata port 6 sata port 7 sata port 8 p.89
• Network stack disabled p.89
• Network stack configuration p.89
• Csm support enabled p.90
• Csm configuration p.90
• Other pci devices legacy p.91
• Option rom messages force bios p.91
• Network storage video legacy p.91
• Iscsi configuration p.91
• Gatea20 active upon request p.91
• Boot option filter legacy only p.91
• Security menu p.92
• Administrator password p.92
• User password p.93
• Secure boot mode custom p.93
• Secure boot menu p.93
• Secure boot control disabled p.93
• Key management p.94
• Bootup numlock state on p.94
• Boot menu p.94
• Set the booting order of network devices p.95
• Network device bbs priorities p.95
• Chassis intrusion message warning p.95
• Boot option priorities p.95
• Boot logo display disabled p.95
• Tool menu p.96
• Monitor menu p.96
• Fan speed control generic mode p.96
• Asus ez flash p.96
• Save exit menu p.97
• Save changes and reset p.97
• Restore defaults p.97
• Launch efi shell from filesystem device p.97
• Discard changes and exit p.97
• Boot override p.97
• Smbios event log enabled p.98
• Event logs menu p.98
• Erasing settings p.98
• Erase event log no p.98
• Enabling disabling options p.98
• Change smbios event log settings p.98
• Log system boot event disabled p.99
• Log oem codes enabled p.99
• Custom options p.99
• Convert oem codes disabled p.99
• When log is full do nothing p.99
• Smbios event log standard settings p.99
• Metw 60 p.99
• Meci 1 p.99
• Chapter 4 bios setup p.100
• Chapter 5 raid configuration p.101
• Setting up raid p.102
• Raid definitions p.102
• Setting the raid mode in bios p.103
• Raid configuration utilities p.103
• Installing hard disk drives p.103
• Rapid storage technology enterprise sata option rom utility allows you to create raid 0 raid 1 raid 10 raid 1 0 and raid 5 set from serial ata hard disk drives that are connected to the serial ata connectors supported by the southbridge p.104
• Rapid storage technology enterprise sata option rom utility p.104
• Intel rapid storage technology enterprise sata option rom utility p.104
• Chapter 5 raid configuration p.104
• Before you proceed ensure that you have installed the serial ata hard disk drives and have set the correct sata mode in the bios setup you can refer to sections 5 installing hard disk drives and 5 setting the raid mode in bios for more information p.104
• Turn on the system p.104
• To launch the inte p.104
• To display the utility main menu p.104
• The raid bios setup screens shown in this section are for reference only and may not exactly match the items on your screen p.104
• The navigation keys at the bottom of the screen allow you to move through the menus the navigation keys at the bottom of the screen allow you to move through the menus and select the menu options p.104
• The inte p.104
• When you are done p.105
• To select the hard disk drives that you want to include in the raid set p.105
• To create a raid set p.105
• Creating a raid set p.105
• Asus p10s v 4l p.105
• To return to the delete volume menu p.107
• To delete a raid set p.107
• Take caution when deleting a raid set you will lose all data on the hard disk drives when you delete a raid set p.107
• Deleting a raid set p.107
• Asus p10s v 4l p.107
• When you are done p.108
• To return to the utility main menu p.108
• To reset a raid set p.108
• Take caution before you reset a raid volume hard disk drive to non raid resetting a raid volume hard disk drive deletes all internal raid structure on the drive p.108
• Resetting disks to non raid p.108
• Chapter 5 raid configuration p.108
• Rebuilding the raid with other non raid disk p.109
• Rebuilding the raid p.109
• Rapid storage technology enterprise sata option rom utility p.109
• Exiting the intel rapid storage technology enterprise sata option rom utility p.109
• Exiting the inte p.109
• Rebuilding the raid with a new hard disk p.110
• Setting the boot array in the bios setup utility p.111
• Rapid storage technology enterprise windows p.112
• Intel rapid storage technology enterprise windows p.112
• Creating a raid set p.113
• Changing a volume type p.115
• Deleting a volume p.116
• Preferences p.117
• Chapter 5 raid configuration p.118
• Chapter 6 driver installation p.119
• Server 2008 os installation p.120
• Raid driver installation p.120
• Installing the raid controller driver p.120
• During window p.120
• Creating a usb flash drive with raid driver p.120
• Running the support dvd p.123
• Manual p.123
• Management applications and utilities installation p.123
• Drivers p.123
• Contact p.123
• Asus p10s v 4l 6 5 p.123
• When you place the support dvd into the optical drive the dvd automatically displays the main screen if autorun is enabled in your computer by default the drivers tab is displayed p.123
• Utilities p.123
• The support dvd that is bundled with your motherboard contains drivers management applications and utilities that you can install to maximize the features of your motherboard p.123
• The main screen of the support dvd contains the following tabs p.123
• Utilities menu tab p.124
• Drivers menu tab p.124
• Manual menu p.125
• Contact information menu p.125
• Installing the intel chipset device software driver p.126
• Installing the intel p.126
• Chipset device software driver p.126
• Installing the intel i210 gigabit adapters driver p.128
• Installing the intel p.128
• I210 gigabit adapters driver p.128
• Installing the vga driver p.131
• Appendix p.133
• P10s v 4l block diagram p.134
• Appendix p.134
• Simplified eu declaration of conformity p.135
• Asus p10s v 4l p.135
• Technical support p.136
• Asustek computer inc taiwan p.136
• Asustek computer inc china p.136
• Asustek computer inc p.136
• Asus contact information p.136
• Technical support p.137
• Asus czech service s r o europe p.137
• Asus contact information p.137
• Asus computer international america p.137
• Asus computer gmbh germany and austria p.137
• Asus contact information p.138
• Ask service russia and cis p.138
• Technical support p.138
• Asus polska sp z o o poland p.138
• Asus holland bv the netherlands p.138
• Declaration of conformity p.139
• Ca 94539 p.139
• Asus computer international p.139
• Appendix p.140
