Cordless multi-function tool
6
To
switch
on the power tool, slide the on/
off switch for ward so that “I” appears on the
switch.
To
switch off
the power tool, slide the on/off
switch backward so that “0” appears on the
switch.
Note:
If the power tool shuts down automat-
ically because the battery is fl at or overheat-
ed, switch the power tool off using the on/off
switch.
Charge the battery or let it cool down before
switching the power tool on again. Failure to
do so can damage the battery.
Preselecting the orbital stroke rate
You can even preselect the required orbital
stroke rate during operation using the orbital
stroke rate preselection thumbwheel.
The required orbital stroke rate is dependent
on the material and the work conditions and
can be determined using practical tests.
Practical Advice
►
Remove the battery from the power tool
before carrying out work on the power
tool (e.g. maintenance, changing tool,
etc.). The battery should also be re-
moved for transport and storage.
There
is risk of injury from unintentionally press-
ing the on/off switch.
►
Always wait until the power tool has
come to a complete stop before placing
it down.
Note:
Do not cover or close the ventilation
slots on the power tool when working as this
will reduce the service life of the power tool.
Operating principle
The oscillating drive causes the application
tool to oscillate back and forth by 3.2° up to
19000 times per minute. This enables precise
work in the tightest of spaces.
Use a consistent, low contact
pressure when performing
work; otherwise, the perfor-
mance will be impaired and the
application tool may jam.
While working, move the power
tool back and forth to prevent
the application tool overheating
and jamming.
Sawing
►
Use only undamaged saw blades that
are in perfect condition.
Bent or dull saw
blades can break, negatively infl uence the
cut, or lead to kickback.
►
When sawing lightweight materials,
take into account the statutory provi-
sions and recommendations of the ma-
terial manufacturers.
►
Plunge cuts may only be applied to
soft materials, such as wood, gypsum
board, etc.
Before using HCS saw blades to saw into
wood, chipboard, building materials, etc.,
check these saw blades for foreign objects,
such as nails, screws, etc. Remove the for-
eign objects as required or use bi-metal saw
blades.
Cutting
Note:
When cutting wall tiles, please bear in
mind that the application tools are subject to
high wear if used for extended periods.
Sanding
The material removal rate and sanding result
are primarily determined by the choice of
sanding sheet, the preselected orbital stroke
rate level and the contact pressure.
Only immaculate sanding sheets achieve
good sanding performance and make the
power tool last longer.
Be sure to apply consistent contact pressure
in order to increase the lifetime of the sanding
sheets.
Excessively increasing the contact pressure
will not lead to increased sanding perfor-
mance, rather it will cause more severe wear
of the power tool and of the sanding sheet.
To sand corners, edges and hard-to-reach ar-
eas accurately, you can also work with the tips
alone or with an edge of the sanding plate.
The sanding sheet may heat up signifi cantly
when used to sand specifi c points rather than
entire surfaces. Reduce the orbital stroke rate
and contact pressure and allow the sanding
sheet to cool down at regular intervals.
Do not use a sanding sheet for other materi-
als after it has been used to work on metal.
Use only original Bosch sanding accessories.
Always connect a dust extraction system for
sanding.
Scraping
Select a high orbital stroke rate level for
scraping.
Work on a soft surface (e.g. wood) at a flat
angle and with low contact pressure. Failure
to do so may cause the scraper to cut into the
surface underneath.
Temperature-dependent-overload protec-
tion
In normal conditions of use, the power tool
cannot be overloaded. If the power tool is
overloaded or not kept within the permitted
