Candy CHG6LB [4/62] Adapting the hob to different types of gas

Table A

Burner Type

Ø pan/pot

(cm)

AUX

10 - 18

12 - 22

16 - 26

Auxiliary

Semi Rapid

Rapid

Power

(kW)

1,00

1,75

2,70

G20/20 mbar

(methane)

95 l/h

167 l/h

257 l/h

G30/28-30 mbar

(LPG)

73 g/h

127 g/h

196 g/h

04 GB

2.3. ADAPTING THE HOB TO DIFFERENT

TYPES OF GAS

To adapt the Hob for use with different types of gas, carry out the

following instructions:

•Remove the grids and burners

•Insert on hexagonal spanner (7 mm) into the burner support (Figure

•Unscrew the injector and replace it with one suitable for the gas to be

used (see gas type table)

2.4. REGULATING THE MINIMUM FLAME

After lighting the burners, turn the control knob to the minimum setting

and then remove the knob (this can easily be removed by applying

gentle pressure).

Using a small «Terminal» type screwdriver the regulating screw can

be adjusted as in Turning the screw clockwise reduces theFigure 9.

gas flow, whilst turning it anticlockwise increases the flow – Use this

adjustment to obtain a flame of approximately 3 to 4 mm in length and

then replace the control knob.

When the gas supply available is LPG - the screw to set the idle flame

must be turned (clockwise) to the end stop.

When you have carried out the new gas regulation, replace the old gas

rating plate on your appliance with one (supplied with hob) suitable for

the type of gas for which it has been regulated.

3. USE OF HOB - USER INSTRUCTIONS

This appliance must only be used for the purpose for which it is

intended, domestic cooking, and any other use will be considered

improper and could therefore be dangerous. The Manufacturer will

not be responsible for any damage or loss resulting from improper

use.

3.1. USING THE GAS BURNER

To ignite the burners, place a lighted taper close to the burner, press in

and turn the control knob anti-clockwise.

If the burners have not been used for a couple of days, wait for a few

seconds before lighting the burner, this will allow any air present in the

pipes to escape.

For appliances fitted with electronic ignition carry out the following:

• Push in and turn the knob anticlockwise to the ignition symbol.

• İgnite the burner by pressing the sparker button.

For hobs fitted with automatic ignition simply push in and turn the knob

to the ignition symbol.

The ignition system will continue to generate sparks as long as the

control knob is being pressed.

If the burner has not ignited within 5 seconds, turn the knob to the 0

position and repeat the operation.

For models fitted with a safety tap (which cuts-off the flow of gas if the

flame is accidentally extinguished) the burners are ignited and

described above, but care must be taken.

Prior to switching on the gas hob ensure that the burners and burner

caps are correctly placed within their position.

Warning: If there is no electricity on appliance, to ignite the burner a

lighter should be used;

- Push in and turn the knob anti-clockwise to the ignition symbol,

- While pushing in the button ignite the burner by using a lighter and

keep button pushed in 5 seconds after ignition.

GENERALADVISE

For best results, use cooking vessels with a flat surface. The size of

the surface should match the gas burner side as follows.TableA.

4. MAINTENANCE AND CLEANING

Before cleaning the hob, ensure the appliance has cooled down.

Remove the plug from the socket or (if connected directly) switch off

the electricity supply.

Cleaning and user maintenance shall not be made by children without

supervision

Never use abrasives, corrosive detergents, bleaching agents or

acids. Avoid any acid or alkaline substances (lemon, juice, vinegar

etc.) on the enamelled, varnished or stainless steel sections.

When cleaning the enamelled, varnished or chrome sections, use

warm soapy water or a non caustic detergent. For stainless steel use

an appropriate cleaning solution.

The burners can be cleaned with soapy water. To restore their original

shine, use a household stainless steel cleaner.After cleaning, dry the

burners and replace.

It is important the Burners are replaced correctly.

Chromed grids and burners

Chromed grids and burners have a tendency to discolour with use.

This does not jeopardize the functionality of the hob.

Our After Sales Service Centre can provide spare parts if required.

For smaller containers the gas burner should be regulated so that the

flame does not overlap the base of the pan. Vessels with a concave or

convex base should not be used.

WARNING: If a flame is accidentally extinguished, turn the knob

to the off position and do not attempt to re-ignite if for at least 1

minute.

If over the years the gas taps become stiff to turn it is necessary to

lubricate them.

Such operation must be carried out only by qualified Service

Engineers.

2)Tighten the joints with the spanner, remembering to twist the

pipes into position.

3)Attach fitting C to mains gas supply using rigid copper pipe or

flexible steel pipe.

IMPORTANT: carry out a final check for leaks on the pipe

connections using a soapy solution. NEVER USE A FLAME.

Also, make sure that the flexible pipe cannot come into contact

with a moving part of the cabinet (eg.adrawer) and that it is not

situated where it could be damaged.

Warning: If gas can be smelt in the vicinity of this appliance turn off

the gas supply to the appliance and call the engineer directly. Do not

search for a leak with a naked flame.

Before using burner, be sure, grid perimeters center the burner as

below figure.

If you are using Cast Iron Grids; underneath the grid, position of it is

stated. Be sure for the exact grid is used in correct position.
