![Daikin FTKS50BVMA [6/84] Wipe clean flat panel](/views2/1773526/page6/bg6.png)
EDAU04-309A Features
Room Air Conditioners B-Series 5
03RAGH-11
3. Wipe-clean Flat Panel
Wall Mounted
Grille Type : Remove and wash the grille
Current models are …
New Flat Panel : Easy to clean without removing the panel
New models are …
Also washable after
removing the panel.
03RAGH-13
= Just one push of the [SENSOR] button =
Sensor
Intelligent Eye
