![Daikin RYN35CVMB [4/53] Specifications](/views2/1773511/page4/bg4.png)
ELECTRICAL DATA
RN+FTN20C
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FTN20CVMB RN20CVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
13.0 15 42 2.81 25 0.35 18 0.20
3D044326
RN+FTN25C
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FTN25CVMB RN25CVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
13.0 15 47 3.21 25 0.35 18 0.20
3D044327
RN+FTN35C
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FTN35CVMB RN35CVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
13.0 15 70 4.41 25 0.35 18 0.20
3D044328
RS+FTS50B
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FTS50BVMB RS50BVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
18 20 72 6.92 53 0.18 40 0.16
3D040875
RS+FTS60B
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FTS60BVMB RS60BVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
18 20 72 6.92 53 0.24 43 0.16
3D040875
RS+FVKS50B
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FVKS50BVMB RS50BVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
18 20 76 7.04 53 0.18 14+14 0.31
3D040875
RS+FLKS50B
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FLKS50BVMB RS50BVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
18 20 75 7.00 53 0.18 34 0.54
3D040875
SYMBOLS
MCA : Min. Circuit Amps (A)
MFA : Max. Fuse Amps (A)
RHz : Rated operating frequency(Hz)
RLA : Rated Load Amps (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps
W : Rated motor output (W)
NOTES
1. RLA is based on the following conditions:
Indoor temp.: 27°CDB/19.0°CWB
Outdoor temp. : 35°CDB
2. Maximum allowable voltage unbalance between phases is 2%
3. Select wire size based on the larger value of MCA.
4. Instead of fuse, use circuit breaker.
5. For more details concerning conditional connections, see
http://www.daikineurope.com/extranet, select ’’Daikin Documentation’’
and select ’’conditional connection’’, ’’the requested product type’’ and
’’English’’ from the drop down lists, click the search button.
Finally, click on the document title of your choice.
•
Pair Application •
R-410A •
RN20,25,35CVMB • RS50,60BVMB
2
Specifications
26
2
460
• Split - Sky Air • Outdoor Units
