Installation manual
1
FFQ25~60B8V1B
Split System air conditioners
4PW23700-1B
CONTENTS Page
Before installation.............................................................................. 1
Selecting installation site................................................................... 2
Preparations before installation......................................................... 2
Indoor unit installation ....................................................................... 3
Refrigerant piping work ..................................................................... 3
Drain piping work .............................................................................. 4
Electric wiring work ........................................................................... 5
Wiring example and how to set the remote controller ....................... 5
Wiring example ................................................................................. 6
Field setting....................................................................................... 7
Installation of the decoration panel ................................................... 7
Test operation.................................................................................... 7
Wiring diagram .................................................................................. 8
BEFORE INSTALLATION
■ When moving the unit while removing it from the carton box, be
sure to lift it by holding on to the four lifting lugs without exerting
any pressure on other parts, especially on the swing flap, the
refrigerant piping, drain piping, and other resin parts.
■ Leave the unit inside its packaging until you reach the
installation site. Where unpacking is unavoidable, use a sling of
soft material or protective plates together with a rope when
lifting, this to avoid damage or scratches to the unit.
■ Especially, do not unfasten the packing case (top) guarding the
switch box until suspending the unit.
■ Refer to the installation manual of the outdoor unit for items not
described in this manual.
■ Caution concerning refrigerant series R410A:
The connectable outdoor units must be designed exclusively for
R410A.
Precautions
■ Do not install or operate the unit in rooms mentioned below.
- Places with mineral oil, or filled with oil vapour or spray like in
kitchens. (Plastic parts may deteriorate.)
- Where corrosive gas like sulphurous gas exists. (Copper
tubing and brazed spots may corrode.)
- Where volatile flammable gas like thinner or gasoline is used.
- Where machines generating electromagnetic waves exist.
(Control system may malfunction.)
- Where the air contains high levels of salt such as air near the
ocean and where voltage fluctuates a lot (e.g. in factories).
Also in vehicles or vessels.
■ When selecting the installation site, use the supplied paper
pattern for installation.
■ Do not install accessories on the casing directly. Drilling holes in
the casing may damage electrical wires and consequently cause
fire.
Accessories
Check if the following accessories are included with your unit.
See figure 1
Optional accessories
■ There are two types of remote controllers: wired and wireless.
Select a remote controller according to customers request and
install in an appropriate place.
Refer to catalogues and technical literature for selecting a
suitable remote controller.
■ A decoration panel is also required for this indoor unit.
FFQ25B8V1B
FFQ35B8V1B
FFQ50B8V1B
FFQ60B8V1B
Split System air conditioners
Installation manual
READ THESE INSTRUCTIONS CAREFULLY BEFORE
INSTALLATION. KEEP THIS MANUAL IN A HANDY
PLACE FOR FUTURE REFERENCE.
IMPROPER INSTALLATION OR ATTACHMENT OF
EQUIPMENT OR ACCESSORIES COULD RESULT IN
ELECTRIC SHOCK, SHORT-CIRCUIT, LEAKS, FIRE OR
OTHER DAMAGE TO THE EQUIPMENT. BE SURE ONLY
TO USE ACCESSORIES MADE BY DAIKIN WHICH ARE
SPECIFICALLY DESIGNED FOR USE WITH THE
EQUIPMENT AND HAVE THEM INSTALLED BY A
PROFESSIONAL.
IF UNSURE OF INSTALLATION PROCEDURES OR USE,
ALWAYS CONTACT YOUR DAIKIN DEALER FOR
ADVICE AND INFORMATION.
1 Drain hose
2 Metal clamp
3 Washer for hanger bracket
4 Paper pattern for installation
5 Srews (M5) for paper pattern for installation
6 Insulation for gas pipe fitting
7 Insulation for liquid pipe fitting
8 Large sealing pad
9 Small sealing pad
10 Sealing material
11 Installation manual and operation manual
