Daikin FFQ60B8V1B [8/14] Electric wiring work
![Daikin FFQ60B8V1B [8/14] Electric wiring work](/views2/1775141/page8/bg8.png)
Installation manual
5
FFQ25~60B8V1B
Split System air conditioners
4PW23700-1B
When electric wiring work is not finished
■ Remove the switch box lid and connect the power supply to
the terminals.
See figure 17.
■ After confirming drainage, turn off the power and disconnect
the single phase power supply.
■ Note that the fan also starts rotating.
■ Attach the switch box lid as before.
ELECTRIC WIRING WORK
General instructions
■ All field supplied parts and materials and electric works must
conform to local codes.
■ Use copper wire only.
■ Follow the 'Wiring diagram' attached to the unit body to wire the
outdoor unit, indoor units and the remote controller. For details
on hooking up the remote controller, refer to the "Installation
manual of the remote controller".
■ All wiring must be performed by an authorized electrician.
■ A circuit breaker capable of shutting down power supply to the
entire system must be installed.
■ Note that the operation will restart automatically if the main
power supply is turned off and then turned back on again.
■ Refer to the installation manual attached to the outdoor unit for
the size of power supply electric wire connected to the outdoor
unit, the capacity of the circuit breaker and switch, and wiring
instructions.
■ Be sure to ground the air conditioner.
■ Do not connect the ground wire to gas pipes, water pipes,
lightning rods, or telephone ground wires.
• Gas pipes: might cause explosions or fire if gas leaks.
•Water pipes: no grounding effect if hard vinyl piping is used.
•Telephone ground wires or lightning rods: might cause
abnormally high electric potential in the ground during lightning
storms.
Electrical characteristics
Specifications for field wire
WIRING EXAMPLE AND HOW TO SET THE
REMOTE CONTROLLER
How to connect wiring (See figure 22)
■ Wiring between units and ground wire
Remove the control box lid and connect wires of matching
number to the power supply terminal block (4P) inside. (See C).
And connect the ground wire to the terminal block. In doing this,
pull the wires inside through the hole and fix the wires securely
with a field supplied clamp. (See B).
■ Give enough slack to the wires between the clamp and power
supply terminal block. (Use the figure as a guide and allow at
least 80 mm for removing the sheath.)
■ Pull the wires inside through the hole and connect to the
terminal block for remote controller (6P). (See A). (no polarity)
Securely fix the remote controller cord with a field supplied
clamp.
■ Give enough slack to the wires between the clamp and the
terminal block for the remote controller.
■ After connection, attach sealing material. (See D).
■ Be sure to attach the sealing material to prevent the infiltration of
water, as well as of any insects or other small creatures. Other-
wise a short circuit may occur inside the control box. (See D).
1 Switch box lid
2 Remove the switch box lid (take off 2 screws)
3 Power supply terminal block
4 DO NOT CONNECT
The drain pump will not work in this case.
NOTE
For details, refer to "Electrical data".
Wire
Size (mm
2
)
Length
Between
indoor units
H05VV-U4G
(1) (2)
(1) Shows only in case of protected pipes. Use H07RN-F in case of no protection.
(2) Run transmission wiring between the indoor and outdoor units through a conduit
to protect against external forces, and feed the conduit through the wall together
with refrigerant piping.
2,5 —
Unit-Remote
controller
Vinyl cord with sheath
or cable (2 wires)
(3)
(3) For European and Asian market: Vinyl cord with sheath or cable (insulated
thickness: 1 mm or more)
For Australian regular: Shield wire (insulated thickness: 1 mm or more)
0.75~1.25 Max. 500 m
(4)
(4) This length shall be the total extended length in the system of the group control.
Wiring to ground
terminal
Ground wire conform
with local regulations
2.0 —
A Wiring remote controller cord
B Wiring between units
C How to connect power supply terminal block (4P) with ground wire
D How to attach sealing material
1 Control box lid
2 Wiring diagram label (on the backside of the control box lid)
3 Remote controller cord (Ground the shield part of the shielded
wire.)
4 Ter minal block for remote controller (6P)
5 Wiring between units
6 Power supply terminal block
7 Big clamp (field supply)
8 Small clamp (field supply)
9 Clamp material
10 Outdoor unit
11 Indoor unit
12 Sealing material (supplied with the unit)
13 Wiring to outside
14 Outside
15 Inside
