SiBE04-808_C Troubleshooting
Service Diagnosis 93
4.6 Refrigerant Shortage
Error Code
U0
Method of Error
Detection
Refrigerant shortage detection I:
Refrigerant shortage is detected by checking the input current value and the compressor
running frequency. If the refrigerant is short, the input current is lower than the normal value.
Refrigerant shortage detection II:
Refrigerant shortage is detected by checking the discharge pipe temperature and the opening of
the electronic expansion valve. If the refrigerant is short, the discharge pipe temperature tends
to rise.
Refrigerant shortage detection III:
Refrigerant shortage is detected by checking the difference between suction and discharge
temperature.
Error Decision
Conditions
Refrigerant shortage detection I:
The following conditions continue for 7 minutes.
<20/25/35/42 class, ARXS50G3V1B>
Input current × input voltage
≤
A × output frequency + B
Output frequency > C
<RK(X)S50G2V1B, ARXS50G2V1B>
Input current
≤
D × output frequency + E
Output frequency > F
Refrigerant shortage detection II:
The following conditions continue for 80 seconds.
Opening of the electronic expansion valve ≥ G
Discharge pipe temperature > H × target discharge pipe temperature + J
A
(–)
B (W) C (Hz)
20/25/35 class 640/256 0 55
42 class 3446/256 –346 48
ARXS50G3V1B 2000/256 –181 55
D
(–)
E
(A)
F
(Hz)
RK(X)S50G2V1B
ARXS50G2V1B
18/1000 0.7 55
G (pulse) H (–) J (°C)
20/25/35 class 480 128/128 30
42 class 450 128/128 40
RK(X)S50G2V1B
ARXS50G2V1B
480 128/128 cooling: 20, heating: 45
ARXS50G3V1B 480 128/128 cooling: 60, heating: 45
