SiBE04-808_C Specifications
Specifications 11
50 Hz, 220 - 230 - 240 V
Note:
The data are based on the conditions shown in the table below.
Models
Indoor Unit FTXS35G2V1B FTXS20G2V1B
Outdoor Unit
RXS35G2V1B RXS20G2V1B9
Cooling Heating Cooling Heating
Capacity Rated (Min. ~ Max.)
kW 3.5 (1.4 ~ 4.0) 4.0 (1.4 ~ 5.2) 2.0 (1.3 ~ 2.8) 2.7 (1.3 ~ 4.3)
Btu/h 11,900 (4,800 ~ 13,600) 13,600 (4,800 ~ 17,700) 6,800 (4,400 ~ 9,600) 9,200 (4,400 ~ 14,700)
kcal/h 3,010 (1,200 ~ 3,440) 3,440 (1,200 ~ 4,470) 1,720 (1,120 ~ 2,410) 2,320 (1,120 ~ 3,700)
Moisture Removal L/h 1.9 — 0.9 —
Running Current (Rated) A 4.4 - 4.2 - 4.0 4.8 - 4.6 - 4.4 2.8 - 2.7 - 2.5 3.6 - 3.5 - 3.3
Power Consumption
Rated (Min. ~ Max.)
W 870 (350 ~ 1,190) 960 (340 ~ 1,460) 470 (320 ~ 910) 630 (310 ~ 1,360)
Power Factor % 89.9 - 90.1 - 90.6 90.9 - 90.7 - 90.9 76.3 - 75.7 - 78.3 79.5 - 78.3 - 79.5
COP (Rated) W/W 4.02 (4.00 ~ 3.96) 4.17 (4.12 ~ 3.56) 4.26 (4.06 ~ 3.08) 4.29 (4.19 ~ 3.16)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ 18.0 φ 18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. lnterunit Piping Length m 20 20
Max. lnterunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit FTXS35G2V1B FTXS20G2V1B
Front Panel Color White White
Airflow Rate
H
m³/min
(cfm)
10.4 (367) 10.6 (374) 9.4 (332) 9.9 (350)
M 7.7 (270) 8.5 (302) 7.4 (262) 8.2 (290)
L 4.8 (170) 6.4 (226) 5.5 (193) 6.5 (228)
SL 3.5 (125) 5.4 (191) 4.0 (141) 5.5 (193)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.12 - 0.12 - 0.11 0.13 - 0.13 - 0.12 0.09 - 0.08 - 0.08 0.10 - 0.10 - 0.09
Power Consumption (Rated) W 26 - 26 - 26 28 - 28 - 28 18 - 18 - 18 21 - 21 - 21
Power Factor % 98.5 - 94.2 - 98.5 97.9 - 93.6 - 97.2 90.9 - 97.8 - 93.8 95.5 - 91.3 - 97.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 274 × 870 × 366 274 × 870 × 366
Weight (Mass) kg 10 9
Gross Weight (Gross Mass) kg 13 13
Sound
Pressure
Level
H / M / L / SL dB(A) 42 / 34 / 26 / 23 42 / 36 / 29 / 26 38 / 32 / 25 / 22 38 / 33 / 28 / 25
Sound Power Level dB 58 58 54 54
Outdoor Unit RXS35G2V1B RXS20G2V1B9
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AFXD 1YC23AEXD
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 1.20 0.80
Airflow Rate
H
m³/min
(cfm)
36.0 (1,272) 30.2 (1,066) 36.2 (1,278) 30.6 (1,080)
SL 31.4 (1,109) 22.6 (798) 32.7 (1,153) 28.5 (1,005)
Fan
Type Propeller Propeller
Motor Output W 50 23
Running Current (Rated) A 4.26 - 4.08 - 3.91 4.71 - 4.50 - 4.31 2.67 - 2.55 - 2.45 3.50 - 3.35 - 3.21
Power Consumption (Rated) W 844 - 844 - 844 932 - 932 - 932 452 - 452 - 452 609 - 609 - 609
Power Factor % 90.1 - 89.9 - 89.9 89.9 - 90.0 - 90.1 76.9 - 77.1 - 76.9 79.1 - 79.0 - 79.0
Starting Current A 4.8 3.6
Dimensions (H × W × D) mm 550 × 765 × 285 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 612 × 906 × 364 612 × 906 × 364
Weight (Mass) kg 34 32
Gross Weight (Gross Mass) kg 40 35
Sound
Pressure
Level
H / SL dB(A) 48 / 44 48 / 45 46 / 43 47 / 44
Sound Power
Level
HdB63636162
Drawing No. 3D059724 3D066468
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
5 m
