EDBE 07-670 Dimensions
Room Air Conditioners C-Series, E-Series 11
4.2 Outdoor Units
RKS25E2V1B, RKS35E2V1B, RXS25E2V1B, RXS35E2V1B
LIQUID
STOP VALVE
(
φ
6.4CuT
)
HANDLE
285
DRAIN OUTLET
(
I.D
φ
15.9 HOSE FOR CONNECTION
)
8
311
13
12
550
29.5
574
765
490
BRAND NAME LABEL
4 - HOLES FOR ANCHOR BOLTS
(
M8 OR M10
)
63
105.5
WIRING
INLET
NAME
PLATE
SERVICE
PORT
IN CASE OF REMOVING
STOP VALVE COVER
MINIMUM SPACE FOR AIR PASSAGE
50
196
100
105
50
165
150
GAS STOP VALVE
(
φ
9.5CuT
)
WALL HEIGHT ON AIR OUTLET SIDE
=LESS THAN 1200
22
50
OUTDOOR AIR THERMISTOR
100
50
150300
3D041800H
