Specifications EDBE 07-670
6 Room Air Conditioners C-Series, E-Series
EDBE 07-670
3. Specifications
3.1 Cooling Only
Duct Connected Type
Note: 1. The data are based on the conditions shown in the table below.
50Hz 230V
Model
Indoor Units FDKS25EAVMB FDKS35EAVMB
Outdoor Units RKS25E2V1B RKS35E2V1B
Capacity
Rated (Min.~Max.)
kW 2.4 (1.3~3.0) 3.4 (1.4~3.8)
Btu/h 8,150 (4,400~10,200) 11,600 (4,800~13,000)
kcal/h 2,060 (1,110~2,580) 2,920 (1,200~3,260)
Moisture Removal L/h 1.2 1.9
Running Current (Rated) A 4.0 5.0
Power Consumption
Rated
W 690 1,090
Power Factor % 75.4 95.0
COP
Rated
W/W 3.48 3.12
Piping
Connections
Liquid mm f6.4 f6.4
Gas mm f9.5 f9.5
Drain mm VP20(O.D.f26/I.D.f20) VP20(O.D.f26/I.D.f20)
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit FDKS25EAVMB FDKS35EAVMB
External Static Pressure Pa 30 30
Air Flow
Rate
m
3
/min
(cfm)
H 8.7 (307) 8.7 (307)
M 8.0 (282) 8.0 (282)
L 7.3 (258) 7.3 (258)
SL 6.2 (219) 6.2 (219)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 62 62
Speed Steps 5 Steps,silent,auto 5 Steps,silent,auto
Air Filter Removable, Washable, Mildew Proof Removable/washable/mildew Proof
Running Current (Rated) A 0.48 0.48
Power Consumption (Rated) W 71 71
Power Factor % 64.3 64.3
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 200×700×620 200×700×620
Packaged Dimensions (H×W×D) mm 274×906×751 274×906×751
Weight kg 21 21
Gross Weight kg 29 29
Operation
Sound
Sound
Pressure
H/M/L/SL dBA 35/33/31/29 35/33/31/29
Sound
Power
H dBA 53 53
Outdoor Unit RKS25E2V1B RKS35E2V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD#C 1YC23NXD#C
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R410A R410A
Charge kg 1.0 1.0
Air Flow
Rate
m
3
/min (cfm)
H 33.5 (1,183) 33.5 (1,183)
L 23.4 (826) 23.4 (826)
Fan
Type Propeller Propeller
Motor Output W 23 23
Running Current (Rated) A 3.50 4.51
Power Consumption (Rated) W 619 1019
Power Factor % 76.9 98.2
Starting Current A 4.3 5.5
Dimensions (H×W×D) mm 550×765×285 550×765×285
Packaged Dimensions (H×W×D) mm 617×882×363 617×882×363
Weight kg 32 32
Gross Weight kg 38 38
Operation
Sound
Sound
Pressure
H/L dBA 46/43 47/44
Sound
Power
H dBA 61 62
Drawing No. 3D057661 3D057662
Cooling Piping Length
Indoor;27°CDB/19°CWB
Outdoor;35°CDB/24°CWB
7.5m
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m
3
/min×35.3
