EDBE 07-670 Functions
Room Air Conditioners C-Series, E-Series 5
Note: h : Optional Accessory
k : Holding Functions
— : No Functions
Category Functions
FDKS25EAVMB
RKS25E2V1B
FDKS35EAVMB
RKS35E2V1B
FDKS25CAVMB
RKS25E2V1B
FDKS35CAVMB
RKS35E2V1B
FDXS25EAVMB
RXS25E2V1B
FDXS35EAVMB
RXS35E2V1B
FDXS25CAVMB
RXS25E2V1B
FDXS35CAVMB
RXS35E2V1B
Health & Clean Air Purifying Filter ————————
Photocatalytic Deodorizing Filter ————————
Air Purifying Filter with Photocatalytic Deodorizing
Function
————————
Titanium Apatite Photocatalytic Air-Purifying Filter ————————
Longlife Filter ————————
Mold Proof Air Filter kkkkkkkk
Wipe-clean Flat Panel ————————
Washable Grille ————————
Flash Streamer Air Purifying Operation ————————
Fresh Air Supply Ventilation ————————
Mold Shock Operation ————————
Mold Proof Operation ————————
Mold Proof Stick ————————
Mold Proof Drain Pan ————————
Heating Dry Operation ————————
Antibacterial Fan ————————
Catechin fan ————————
Comfort Sleep Operation ————————
Good-Sleep Cooling Operation ————————
Timer Weekly Timer ————————
24-Hour On/ Off Timer kkkkkkkk
Count Up-Down Timer ————————
Night Set Mode kkkkkkkk
Flexibility Multi-Split/ Split Type Compatible Indoor Unit kkkkkkkk
Flexible Voltage Correspondence ————————
Chargeless 10m 10m 10m 10m 10m 10m 10m 10m
Either Side Drain (Right or Left) ————————
Power Selection ————————
Max. Interunit Piping Length 20m 20m 20m 20m 20m 20m 20m 20m
Max. Installation Height Difference 15m 15m 15m 15m 15m 15m 15m 15m
Other Functions Auto-Restart (after Power Failure) kkkkkkkk
Self-Diagnosis (Digital, LED) Display kkkkkkkk
Wiring-Error Check ————————
Anticorrosion Treatment of Outdoor Heat
Exchanger
kkkkkkkk
Remote Control 5-Rooms Centralized Controller hhhhhhhh
Remote Control Adaptor (Normal Open-Pulse) hhhhhhhh
Remote Control Adaptor (Normal Open Contact) hhhhhhhh
Dlll-NET Compatible (Adaptor) hhhhhhhh
Remote Controller Wireless kkkkkkkk
Wired ————————
