Si04-703A Outdoor Unit
Removal Procedure 169
9
Release the clamp by
pliers.
71 class only.
10
Release the clamp and
undo the wire from the
hook.
11
Lift the electrical box
and remove it.
Step
Procedure Points
(R5277)
