Si04-703A Specifications
Specifications 13
50Hz 220-230-240V / 60Hz 220-230V
Note:
The data are based on the conditions shown in the table below.
Models
Indoor Units FTKS71FVMA
Outdoor Units RKS71FVMA
Capacity
Rated (Min.~Max.)
kW 7.1 (2.3~8.5)
Btu/h 24,200 (7,800~29,000)
kcal/h 6,110 (1,980~7,310)
Running Current (Rated) A 10.8-10.4-9.9 / 10.8-10.4
Power Consumption
Rated (Min.~Max.)
W 2,360 (570~3,200)
Power Factor % 99.3-98.7-99.3 / 99.3-98.7
COP
Rated (Min.~Max.)
W/W 3.01 (4.04~2.66)
Piping
Connections
Liquid mm
φ
6.4
Gas mm
φ
15.9
Drain mm
φ
18.0
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30
Min. Interunit Piping Length m 1.5
Max. Interunit Height Difference m 20
Chargeless m 10
Amount of Additional Charge of
Refrigerant
g/m 20
Indoor Units FTKS71FVMA
Front Panel Color White
Airflow Rate
m³/min
(cfm)
H 17.4 (614)
M 14.6 (516)
L 11.9 (420)
SL 11.2 (395)
Fan
Type Cross Flow Fan
Motor Output W 43
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.21-0.20-0.19 / 0.21-0.20
Power Consumption (Rated) W 45
Power Factor % 97.4-97.8-98.7 / 97.4-97.8
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366
Weight kg 12
Gross Weight kg 17
Operation
Sound
H/M/L/SL dBA 46 / 42 / 37 / 34
Sound Power dBA 62
Outdoor Units RKS71FVMA
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC63BXD
Motor Output W 1,920
Refrigerant
Oil
Type FVC50K
Charge L 0.75
Refrigerant
Type R-410A
Charge kg 2.3
Airflow Rate
m³/min
(cfm)
HH 57.1 (2,016)
H 54.5 (1,924)
L 46.0 (1,624)
Fan
Type Propeller
Motor Output W 66
Running Current (Rated) A 10.59-10.20-9.71 / 10.59-10.20
Power Consumption (Rated) W 2,315
Power Factor % 99.4-98.7-99.3 / 99.4-98.7
Starting Current A 10.8
Dimensions (H×W×D) mm 770×900×320
Packaged Dimensions (H×W×D) mm 900×925×390
Weight kg 71
Gross Weight kg 80
Operation
Sound
H/SL dBA 52 / 49
Sound Power H dBA 66
Drawing No. 3D054878B
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
