Outdoor Unit Si04-703A
206 Removal Procedure
5
Remove the fixture.
3. Removing the Four way
valve coil and motorized
valve coil
1
Remove the screw.
2
Remove the Four way
valve coil.
Step Procedure Points
(R6456)
(R6457)
(R6458)
