Outdoor Unit Si04-703A
192 Removal Procedure
2
Slide the panel leftward
to undo the hook, and
remove the partition
plate.
3
Remove the 3 screws.
4
Remove the wire fixing
plate.
Step Procedure Points
(R6997)
Hook
(R6998)
(R6999)
