Specifications Si04-703A
10 Specifications
1. Specifications
1.1 Cooling Only
50Hz 220-230-240V / 60Hz 220-230V
Note:
The data are based on the conditions shown in the table below.
Model
Indoor Units FTKS50FVM FTKS60FVM
Outdoor Units RKS50FVM RKS60FVM
Capacity
Rated (Min.~Max.)
kW 5.0 (1.7~6.0) 6.0 (1.7~6.7)
Btu/h 17,100 (5,800~20,500) 20,500 (5,800~22,900)
kcal/h 4,300 (1,460~5,160) 5,160 (1,460~5,760)
Running Current Rated A 7.2-6.9-6.6/7.2-6.9 9.2-8.8-8.4/9.2-8.8
Power Consumption
Rated (Min.~Max.)
W 1,550 (440~2,080) 1,990 (440~2,400)
Power Factor % 97.9-97.7-97.9/97.9-97.7 98.3-98.3-98.7/98.3-98.3
COP
Rated (Min.~Max.)
W/W 3.23 (3.86~2.88) 3.02 (3.86~2.79)
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30 30
Max. Interunit Height Difference m 20 20
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit FTKS50FVM FTKS60FVM
Front Panel Color White White
Airflow Rate
m³/min
(cfm)
H 14.7 (519) 16.2 (572)
M 12.6 (445) 13.9 (491)
L 10.2 (360) 11.5 (406)
SL 9.2 (325) 10.0 (353)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof
Running Current (Rated) A 0.16-0.15-0.15/0.16-0.15 0.19-0.18-0.17/0.19-0.18
Power Consumption (Rated) W 34 40
Power Factor % 96.6-98.6-94.4/96.6-98.6 95.7-96.6-98.0/95.7-96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L/SL dBA 43/39/34/31 45/41/36/33
Outdoor Unit RKS50FVM RKS60FVM
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36BXD 2YC36BXD
Motor Output W 1,100 1,100
Refrigerant Oil
Type FVC50K FVC50K
Charge L 0.65 0.65
Refrigerant
Type R-410A R-410A
Charge kg 1.50 1.50
Airflow Rate m³/min (cfm)
HH 50.9 (1,797) 54.2 (1,914)
H 48.9 (1,727) 50.9 (1,797)
L 41.7 (1,472) 45.0 (1,589)
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current (Rated) A 7.04-6.75-6.45/7.04-6.75 9.01-8.62-8.23/9.01-8.62
Power Consumption (Rated) W 1,516 1,950
Power Factor (Rated) % 97.9-97.6-97.9/97.9-97.6 98.4-98.4-98.7/98.4-98.4
Starting Current A 7.2 9.2
Dimensions (H×W×D) mm 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 792×960×390 792×960×390
Weight kg 47 47
Gross Weight kg 52 52
Operation
Sound
H/SL dBA 47/44 49/46
Drawing No. 3D056225 3D056226
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
