Daikin FTXS35D3VMW [10/24] Specifications
![Daikin FTXS35D3VMW [10/24] Specifications](/views2/1780135/page10/bga.png)
3
1
2
• Split Sky Air • Indoor Units 2
• Indoor Units • R-410A • FTXS-D3VMW_D2VMW
2 Specifications
2-1 FOR INDOOR UNITS ONLY
FTXS20D 3VMW FTXS2 5D3VMW FTXS35D3VMW FTXS50D 2V1W
Nominal Input Cooling kW 0.035 0.035 0.040 0.048
Heating kW 0.035 0.035 0.040 0.048
2-2 TECHNICAL SPECIFICATIONS
FTXS20D 3VMW FTXS2 5D3VMW FTXS35D3VMW FTXS50D 2V1W
Casing Colour White
Dimensions Packing Height mm 340 340 340 340
Width mm 855 855 855 855
Depth mm 265 265 265 265
Unit Height mm 283 283 283 283
Width mm 800 800 800 800
Depth mm 195 195 195 195
Weight Unit kg 9.0 9.0 9.0 9.0
Packed Unit kg 12.0 12.0 12.0 12.0
Heat
Exchanger
Dimensions Length mm 610 610 610 610
Nr of Rows 2 2 2 2
Fin Pitch mm 1.40 1.40 1.40 1.40
Nr of Stages 12 12 12 14
Tube type Hi-XA (7)
Fin Type ML fin (Multi louver)
Fan Type Cross flow fan
Air Flow Rate Cooling High m³/min 8.7 8.7 8.9 11.4
Medium m³/min 6.7 6.7 6.9 9.3
Low m³/min 4.7 4.7 4.8 7.1
Silent
Operation
m³/min 3.9 3.9 4.0 6.2
Heating High m³/min 9.4 9.4 9.7 11.4
Medium m³/min 7.6 7.6 7.9 9.4
Low m³/min 5.8 5.8 6.0 7.4
Silent
Operation
m³/min 5.0 5.0 5.2 6.3
Fan Motor Quantity 1 1 1 1
Model KFD-28040-8B KFD-280-40-8B KFD-280-40-8B KFD-280-40-8B
Number of steps 5 steps, silent and auto
Motor Speed
(cooling)
High rpm 1250 1250 1270 1580
Medium rpm 1030 1030 1050 1330
Low rpm 810 810 830 1090
Silent
Operation
rpm 710 710 730 980
Speed
(heating)
High rpm 1280 1280 1320 1520
Medium rpm 1090 1090 1120 1290
Low rpm 900 900 920 1060
Silent
Operation
rpm 820 820 840 960
Fan Motor Output
(high)
W 40 40 40 40
Cooling Sound Power High dBA 56.0 56.0 57.0 62.0
Sound
Pressure
High dBA 38.0 38.0 39.0 46.0
Medium dBA 41.0
Low dBA 25.0 25.0 26.0 35.0
Silent
Operation
dBA 22.0 22.0 23.0 32.0
Heating Sound Power High dBA 56.0 56.0 57.0 62.0
Sound
Pressure
High dBA 38.0 38.0 39.0 46.0
Medium dBA 40.0
Low dBA 28.0 28.0 29.0 34.0
Silent
Operation
dBA 25.0 25.0 26.0 31.0
Refrigerant Type R-410A
