Daikin FTXS35D3VMW [3/24] 2 technical specifications
![Daikin FTXS35D3VMW [3/24] 2 technical specifications](/views2/1780135/page3/bg3.png)
• Indoor Units • R-410A • FTKS-D3VMW_D2V1W
1
2
• Split Sky Air • Indoor Units3
2 Specifications
Standard
Accessories
Item Titanium apatite photocatalytic air purification filter
Quantity 2 2 2 2
Item Operation manual
Quantity 1 1 1 1
Item Installation manual
Quantity 1 1 1 1
Item Infrared remote control
Quantity 1 1 1 1
Item Batteries
Quantity 2 2 2 2
Item Remote control holder
Quantity 1 1 1 1
Item Indoor unit fixing screws
Quantity 2 2 2 2
Item Mounting plate
Quantity 1 1 1 1
Notes Sound values are measured in an anechoic room.
Sound pressure level is a relative value, depending on the distance and acoustic environment. For more details,
please refer to sound level drawings of this chapter.
The sound power level is an absolute value indicating the power which a sound source generates.
2-3 ELECTRICAL SPECIFICATIONS
FTK S2 0D3VMW FTKS25D3 VMW FTKS35D3VMW FTK S5 0D2V1W
Power Supply Name VM VM VM V1
Phase 1 1 1 1
Frequency Hz 50/60 50/60 50/60 50
Voltage V 220-240/220-230 220-240/220-230 220-240/220-230 220-240
Current Nominal
running current
(RLA)
Cooling A 0.16 0.16 0.18 0.21
Wiring
connections
For Power
Supply
Quantity 3 3 3 3
Remark 4 for interunit wiring (included earth wiring)
Voltage range Minimum -10%
Maximum +10%
Power Supply Intake Outdoor unit only
2-2 TECHNICAL SPECIFICATIONS
FTK S2 0D3VMW FTKS25D3 VMW FTKS35D3VMW FTK S5 0D2V1W
